Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue

I'm Online Chat Now

Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue

Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue
Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue

Large Image :  Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: KL-120
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $500.00 / Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month

Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue

Description
Name: Electric Wood Pellet Mill ITEM: Diesel Pellet Mill
Weight (KG): 150 Driven Type: Motor ,diesel Engine
Lubrication System:: Use Recycling Lubrication Oil Pellet Diameter: 3~25 Mm (can Be Selecation)
Warranty: 1 Year Raw Material: Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton
Die Material: Alloy Metal 3CR13 Show Room: Viet Nam, Indonesia
Key Selling: Easy To Operate Voltage: Customized
Certificate: CE ISO Dust Remove System: Cyclone And Bag Dust, To Remove The Dust
Capacity: 800-1000kg/h Application: Making Wood Pellet Fuel And Poultry Feed
High Light:

3CR13 wood pellet machine

,

diesel pellet mill 60HRC

,

electric wood pellet mill bagasse

Electric motor and diesel engine pellet granulator machine wood pellet mill machine

The poultry feed pallet machine is widely used to produce feed pellets and biomass fuel pellets. Wide Application Range: Any kind of biomass materials containing wood fiber, such as peanut shell, bagasse, castor shell, straw, sawdust, coffee grounds, rice husk, sunflower shell, cotton stalk, tobacco residue, leaf mustard stalk, bamboo, jute residue, tea residue, wheat-straw, palm shell, bean shell, coconut shell, dregs of decoction, and wood waste, etc.

Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue 0

Features:

(1) Adopt reduction box with low noise, long lifespan gear and can rotate forward and reverse. Other manufacturers adopt low cost bevel gear that cannot rotate reverse.

(2) The pressing die and main shaft adopt Cr12, which is more wear-resisting because of high Cr content. The special heat treatment makes their hardness to be 60HRC. Other manufacturers use 45# instead with low hardness and wear-resistance.



(3) The roller, pressing die, main shaft and roller shaft are processed by vacuum heat treatment other than carburizing and quenching (that other manufacturers use) to have higher hardness, wear-resistance and longer lifespan.



(4) The sealing of spare parts for small pellet machine is excellent. The roller shaft is sealed on both sides, while other manufacturers only seal one side.



(5) The feeding hopper applies whole sheet metal edge instead of welding to be more stable and firm.



(6) The compression ratio of small pellet press determines the quality of your pellets. We have professional team doing the raw material test and have obtained best compression ratio for over 20 kinds of common seen biomass.



(7) The electric components adopt top brands in China to guarantee stable performance.

Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue 1

Specifications:

Model Motor(kw) Capacity(kg/h) Speed(RPM) Dimension(mm) Weight(kg)
KL-120 3 20-40 320 1020*530*1120 66
KL-125 3 40-50 320 1040*550*1140 78
KL-150 4 75-125 320 1280*600*1250 94
KL-180 7.5 125-175 320 1400*750*1300 138
KL-210 11 200-250 320 1500*850*1400 189
KL-260 15 350-500 380 1900*800*1600 300
KL-300 18.5 500-800 380 2000*860*1700 410
KL-360 30 800-1200 400 2080*900*1750 550
KL-400 337 1200-1500 400 2200*1200*1950 660



Diesel Electric Wood Pellet Machine Mill 3CR13 Alloy Metal Bagasse Tobacco Residue 2

Founded in 2010,MIKIM Machinery Equipment Co., Ltd is specialised in the research, development, production and sales of Wood Crusher Machine, Feed Pellet Machine, Charcoal Machine and Briquette Machine for more than 10 years.

We have got quality certifications of ISO9001, SGS, and CE etc. Machine color, logo, design, package, carton mark, manual etc can be customized! With a production ability of 5000 sets per month, MIKIM is the largest crusher and pellet factory in China.

Wood Crusher Machine, Feed Pellet Machine, Charcoal Machine and Briquette Machine have been exported to England, Russia, Sweden, Poland, Romania, Malaysia, Indonesia, Vietnam etc 120 countries and districts. Warmly welcome clients at home and abroad to visit MIKIM company.
