Product Details:
|
Name: | Poultry Feed Pellet Machine | ITEM: | Pellet Making Machine |
---|---|---|---|
Weight (KG): | 150 | Driven Type: | Motor ,diesel Engine |
Lubrication System:: | Use Recycling Lubrication Oil | Pellet Diameter: | 3~25 Mm (can Be Selecation) |
Warranty: | 1 Year | Raw Material: | Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton |
Die Material: | Alloy Metal 3CR13 | Show Room: | Viet Nam, Indonesia |
Power Supply: | Diesel Engine/gasoline/motor/PTO Driven | Dust Remove System: | Cyclone And Bag Dust, To Remove The Dust |
Capacity: | 950kg/h | Application: | Making Crude Fiber Materials Into Pellets |
High Light: | animal feed pellet machines 114mm,manual feed pellet machine 300kg/ h,fish feed pelletizer 114*47*97mm |
Farms use household small manual pelletized poultry livestock animal feed pellet machine mill for poultry livestock
Wood sawdust pellet machine is an ideal pelletizing machine for small scale fuel pellets production at home, on the farm, in the yard or outside in the open air.The material are widely, such as straw, peanut shells, wood chips, rice husk, cotton stalk, cotton seed hull, weeds and other crops straw.The wood sawdust powder raw material is spread evenly into the space between the flat die and roller, and press into the mould hole, formed column shape pellet, the pellet will rotate along with the rotating ring die mould and will be cutted when the length of the column pellet reach to a certain value.The wood pellet production line is included wood crusher machine,screw conveyor,wood pellet machine.The capacity range is from 100kg/h to 5000kg/h.
1.For feedstuff use:
The compressed straw piece is suitable to be used as fuels and feedstuff of animals, such as horse, sheep,
deer, pig, chicken, etc. Such machines are suitable for large farms, and organic herbal medicine and
chemical industry etc.
2.For wood pellets
For biomass pellets use:This series flat die pellet presses can be used for producing
wood pellets and biomass pellets, too. Wood pellets are made of all kinds of wood waste. Biomass
pellets are made of peanut sheller, corn stalk and other biomass materials.
Technical parameters
Model | Motor Power | Motor voltage | Size | Poutput (kg/h) | Roller diameter | Moisture | |
No. | (KW) | (V) | (MM) | Wood | Feed | (MM) | (%) |
120 | Electric 3 | 220V 50HZ 380V 50HZ | 75*35*65 | 40-60 | 60-100 | 2.5-10 | 12%-20% |
120A | Diesel 8 | - | 87*44*73 | 40-60 | 60-100 | 2.5-10 | 12%-20% |
120B | Gasoline 7.5 | - | 76*42*71 | 40-60 | 60-100 | 2.5-10 | 12%-20% |
150 | Electric 4 | 380V 50HZ | 75*35*65 | 50-90 | 90-120 | 2.5-10 | 12%-20% |
150A | Diesel 8 | - | 87*44*73 | 50-90 | 90-120 | 2.5-10 | 12%-20% |
150B | Gasoline 7.5 | - | 76*42*71 | 50-90 | 90-120 | 2.5-10 | 12%-20% |
200A | Diesel 15 | - | 118*56*95 | 110-140 | 200-300 | 2.5-10 | 12%-20% |
200B | Electric 7.5 | 380V 50HZ | 100*43*95 | 110-140 | 200-300 | 2.5-10 | 12%-20% |
200C | Electric 7.5 | 380V 50HZ | 100*46*90 | 110-140 | 200-300 | 2.5-10 | 12%-20% |
230A | Diesel 22 | - | 118*56*95 | 150-190 | 300-400 | 2.5-10 | 12%-20% |
230B | Electric 11 | 380V 50HZ | 114*47*97 | 150-190 | 300-400 | 2.5-10 | 12%-20% |
230C | Electric 11 | 380V 50HZ | 114*54*93 | 150-190 | 300-400 | 2.5-10 | 12%-20% |
260A | Diesel 35 | - | 184*70*116 | 220-280 | 400-600 | 2.5-10 | 12%-20% |
260B | Electric 15 | 380V 50HZ | 112*52*107 | 220-280 | 400-600 | 2.5-10 | 12%-20% |
260C | Electric 15 | 380V 50HZ | 112*53*107 | 220-280 | 400-600 | 2.5-10 | 12%-20% |
300A | Diesel 55 | - | 227*62*126 | 300-360 | 600-800 | 2.5-10 | 12%-20% |
300B | Electric 22 | 380V 50HZ | 127*52*107 | 300-360 | 600-800 | 2.5-10 | 12%-20% |
300C | Electric 22 | 380V 50HZ | 128*60*105 | 300-360 | 600-800 | 2.5-10 | 12%-20% |
360A | Diesel 55 | - | 227*62*126 | 300-380 | 600-800 | 2.5-10 | 12%-20% |
360C | Electric 22 | 380V 50HZ | 134*58*106 | 300-380 | 600-800 | 2.5-10 | 12%-20% |
400A | Diesel 55 | - | 227*62*126 | 400-550 | 900-1100 | 2.5-10 | 12%-20% |
400C | Electric 30 | 380V 50HZ | 152*60*115 | 400-550 | 900-1100 | 2.5-10 | 12%-20 |
FAQ
1. How is the quality of your products?
Our products are manufactured strictly according to national and international standard,and we take a test on each machine before delivered out.We will send our customers testing video and picture of our equipment after testing.
2.How about price?
We are factory and be able to give you lower price than other trading company.If the products is really suitable and benefit you,the price is negotiable.
3.How about delivery?
We usually deliver the goods out within 10 working days.We will provide the accurate delivery time according to different products.
4.Do you provide equipment operation training?
Yes.We can send our technicians to working site for installation,adjustment and operation training.
5.Do you provide after-sale service?
Yes.Quality guarantee term is for one year.We have a professional after-sale service team to solve problems promptly.If products’ quality don’t accord to description as we give or the promise before you place order,we promise 100% refund.
