CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm

I'm Online Chat Now

CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm

CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm
CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm

Large Image :  CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: KL-120
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $500.00 / Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month

CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm

Description
Name: Poultry Feed Pellet Machine ITEM: Pellet Making Machine
Weight (KG): 350 Driven Type: Motor ,diesel Engine,PTO
Pellet Diameter: 2-12 Mm (can Be Selecation) Warranty: 1 Year
Raw Material: Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton Show Room: Viet Nam, Indonesia,China
Key Selling: Easy To Operate Power Supply: Diesel Engine/gasoline/motor/PTO Driven
Certificate: CE Dust Remove System: Cyclone And Bag Dust, To Remove The Dust
Capacity: 800-1000kg/h
High Light:

CE flat die pelletizer

,

small feed granulator machine pto

,

pto driven pellet mill 12mm

diesel engine/gasoline/motor/PTO driven pellet granulator feed pelletizer wood pellet machine

Flat die animal feed pellet machine for farm is widely used for producing variety materials into high-grade feed pellets for sheep, cattle, poultry, goose, chicken and others.

Main Features

1) Varied driving power, electricty or diesel; environmentally friendly and energy saving.

2) Equipped with the clutch and accelerating-decelerating device to change its speed.

3) Made of wear-resistant material thus having a long service life.

4) Adopt screw-center adjusting pressure structure which makes flat die pellet mill more practical.

5) Can make different feed pellets to meet different production requirements.

6) Adjustable compression rate, the flat die pellet mill can meet different pelletizing requirements and is available to press coarse materials.

7) Can process various kinds of solid grain into small feed pellets for animals like fish, shrimps, chicken, rabbit, and pig; widely used in small aquaculture, grain feed factory, farm, poultry farm, as well as individual farmers.

8) The pelleting process is visible, so it is convenient to solve problems in time.

9) Simple structure, low consumption, small area coverage, easy operation and maintenance.

10) With Diesel flat die pellet mill you can make bedding pellets for animal stalls from cardboard.

CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm 0

Raw material
Wood pellet can be made from any type of agro-forestry waste:
groundnut-shell, sugarcane biogases, caster shells/ stalk, saw dust, coffee husk, paddy straw, sunflower stalk, cotton stalks, tobacco waste, mustard stalk, Jute waste, Bamboo dust, tea waste, wheat straw, Plam husk, soybean husk, coir pitch barks/ straws, rice husks, forestry wastes, wood chips and many other agro wastes.


Model Motor
Power
Motor
voltage
Size output
(kg/h)
Roller diameter Moisture
No. (KW) (V) (MM) Wood Feed (MM) (%)
200A Diesel 15 - 118*56*95 110-140 200-300 2.5-10 12%-20%
200B Electric 7.5 380V 50HZ 100*43*95 110-140 200-300 2.5-10 12%-20%
200C Electric 7.5 380V 50HZ 100*46*90 110-140 200-300 2.5-10 12%-20%
230A Diesel 22 - 118*56*95 150-190 300-400 2.5-10 12%-20%
230B Electric 11 380V 50HZ 114*47*97 150-190 300-400 2.5-10 12%-20%
230C Electric 11 380V 50HZ 114*54*93 150-190 300-400 2.5-10 12%-20%
260A Diesel 35 - 184*70*116 220-280 400-600 2.5-10 12%-20%
260B Electric 15 380V 50HZ 112*52*107 220-280 400-600 2.5-10 12%-20%
260C Electric 15 380V 50HZ 112*53*107 220-280 400-600 2.5-10 12%-20%
300A Diesel 55 - 227*62*126 300-360 600-800 2.5-10 12%-20%
300B Electric 22 380V 50HZ 127*52*107 300-360 600-800 2.5-10 12%-20%
300C Electric 22 380V 50HZ 128*60*105 300-360 600-800 2.5-10 12%-20%
360A Diesel 55 - 227*62*126 300-380 600-800 2.5-10 12%-20%
360C Electric 22 380V 50HZ 134*58*106 300-380 600-800 2.5-10 12%-20%
400A Diesel 55 - 227*62*126 400-550 900-1100 2.5-10 12%-20%
400C Electric 30 380V 50HZ 152*60*115 400-550 900-1100 2.5-10 12%-20




CE Flat Die Pelletizer Small Feed Granulator Machine PTO Driven Pellet Mill 12mm 1
