Product Details:
|
Name: | Fully Automatic Wood Waste Sawdust Screw Briquetting Charcoal Making Machine | Type: | Screw Briquetting Charcoal Briquette Machine |
---|---|---|---|
Warranty: | 12 Months | Capacity: | 400-500kg/h |
Dimension(l*w*h): | 1.9*0.6*1.6m | Weight: | 600 KG |
High Light: | Fully Automatic Charcoal Briquette Maker,Compressed Charcoal Briquette Machine,Fully Automatic Charcoal Briquette Machine |
Competitive Compressed Wood Sawdust Biomass Tree Leaves Bamboo Charcoal Coal Briquettes Press Manufacturing Machines
Model
|
IV
|
ZBJ-500
|
ZBJ-500-30
|
ZBJ-80
|
Power
|
15kw
|
22kw
|
30kw
|
22kw
|
Capacity
|
140-200kg/h
|
360-460kg/h
|
500-600kg/h
|
500-550kg/h
|
Dimension
|
1.67*0.68*1.55m
|
1.9*0.68*1.6m
|
1.9*0.68*1.8m
|
1.9*0.68*1.6m
|
Diameter of briquette
|
50mm
|
50mm,60mm
70mm,80mm
|
50mm,80mm
|
80mm
|
Inlet particle size
|
Within 5mm size
|
|||
Raw material moisture
|
8-12%
|
1. What the main raw material of this machine is?
Its raw materials are mainly sawdust, rice husk, bamboo powder, peanut shell, bagasse, agricultural waste, etc.
2. What does like the finished briquettes?
The main shape is square, hexagon, nine edge, the briquette is 5 to 8cm in diameter with a hole in the middle.
3. How does the briquette making machine operate?
The main working principle of the briquette machine is high temperature, high pressure extrusion and molding, first, you need to turn on electricity, let the heating ring to heat to about 350 degrees, and then open the button, start slowly feeding.
4. Does this machine have wearing parts?
Yes, the main spare parts are inner sleeve, long sleeve and screw propeller. Screw propeller can be repaired after repeated. You can use a welding electrode repairs this part.
5. What is the service life of this machine?
At least 5 years.
