Home ProductsPoultry Feed Pellet Machine

100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW

I'm Online Chat Now

100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW

100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW
100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW 100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW 100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW

Large Image :  100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: BH-150 BH-210 BH-260 BH-300
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $480.00 - 2300.00/ Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW

Name: Animal Poultry Feed Pellet Making Machine Cat Dog Feed Pellet Machine Model: BH-300
Voltage: 220V/380V/customized Capacity: 750KG/H
Weight: 300kg Dimension(l*w*h): 115*45*95CM
Advantage: High Efficiency Easy Operation Final Product: Feed Pellet
Function: Aquatic Feed, Ruminant Feed, Pet Food Spare Parts: Flat Die+ Rollers
High Light:

100KG/ H Poultry Feed Pellet Machine


Poultry Feed Pellet Machine 220V


dog food pellet machine 3KW

Factory Price Animal Poultry Feed Pellet Making Machine cat dog feed pellet machine
Product Description

Introduction of animal feed pellet machine

The working theory of feed pellet machine is that granulation is pressed out from the die hole under the extrusion of the roller pressure, the pellets length can be conveniently adjusted, and various of additive drugs can be added in the processed feed pellets, and the surface of the processed granule is smooth and clean. The hardness is moderate and the internal ripening degree is deep. Dry in dry out, easy to seal and store, natural temperature to 70-80 degrees can kill pathogenic microorganisms and parasites, and ensure feed quality, can be used to raise rabbits, chickens, ducks, geese, fish, pigs, aquatic products, etc.
100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW 0
Technical Parameters of Poultry Feed Pellet Machine
Model Capacity (kg/hr) Power(KW) Weight(kg) Dimension (cm)
BH-125 80-100 3 95 110*35*700
BH-150 110-150 4 98 115*35*80
BH-210 200-300 7.5 280 115*45*95
BH-230 350-450 11 300 138*46*100
BH-260 500-600 15 315 130*53*105
BH-300 700-800 22 600 145*62*120
BH-360 800-900 22 795 160*67*145
BH-400 1000-1200 30 1000 160*67*145
Operation of Poultry Feed Pellet Machine
1: Add oil into gearbox before start.
2:Double-check the belt and the screws before operation.
3:Clean up the rest after use to prevent damage to the machine.
1, Iron or stones cannot be put into the griller.
2:Check the elasticity of the belt, and the bearing frequently. Add oil in time when it needs to.

Application of animal feed pellet machine

Animal feed pellet machine is widely used in large, medium and small aquaculture, grain and feed processing plants, livestock farms, poultry farms, individual farmers and small and medium-sized farms, farmers or large, medium and small feed processing plants.

Final animal feed pellets

Pellets diameter 3-12mm is available.
One machine can produce different diameter of pellets by changing the molds.100kg/ H Dog Poultry Feed Pellet Machine 220V 3KW 1

Matters need attention

1. The new machine for the first time must be run or otherwise can't be used normally.
2. When the pellet machine is working, don't reach into the input hopper by hand. If necessary, you can use a stick to help.
3. Before the machine is turned on, you need to add a little mixture before starting. When the machine is shut down, please leave a little mixture in the machine to prevent the roller and the template idling.
4. When the machine is working, and the phenomenon of stuck happens, should immediately stop and make the roller pressed to the bolt loose, and then restart the machine.
5. Each time the work is completed, the bolt of adjusting roller must be released.
6. If the machine is used for a certain period of time or squeeze out a certain amount of pellets and the pellets are made into pieces or the pellets are broken, the template should be turned to the bottom, and 2%-4% water should be added to the mixture.
7. Please often check the belt tightness to prevent the emergence of low yield, belt slippery and so on.
8. Before starting, firstly add gear oil to the gearbox reaching to 2/3 of the horizontal axis. Pellet machine in the first use should work in low load for 40 hours or so, and then replace the gearbox gear oil, 100 hours after the regular replacement. All bearings should be regularly filled with grease.
9. Particle machine works continuously and then the motor fever reaches to 70 degrees Celsius, it is a normal phenomenon.

1.Why choose you?
a.We are manufacturer, our products have excellent quality and competitive price.
b.We have good after-sales services,you can find us at per 24 hours.
c.Strictly testing and checking before shipping.
2.How to deal the order?
a.Payment terms: T/T 30% as deposit, and 70% before delivery.
b.We'll show you the photos of the products and packages before you pay the balance.
3.Are you interested in dealership with local company?
Yes, we are quite interested in this business. We'd like to cooperate with some local partner to sell more World machines in local
market and supply better service.
4.What is your warranty policy?
We can supply one year warranty for our machines. We will provide parts as free within warranty. We can send engineer to customer
place if big quality problem. We can provide internet or calling service at any time.
5.How do you make our business long-term and good relationship?
a.We keep good quality and competitive price to ensure our customers benefit.
b.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
