Product Details:
|
| Name: | Floating Fish Feed Extruder Machine Fish Feed Making Machine Pet Feed Production Line | Condition: | New |
|---|---|---|---|
| Dimension(l*w*h): | 17*1.2*2.2m | Heating Source: | Electricity, Gas, Diesel, Steam |
| Power(w): | 74KW | Warranty: | 1 Year |
| Capacity: | 120-3500kg/h | Weight: | 380 Kg |
| High Light: | Pet Feed Production Line 1.5cm dia,floating fish feed production line 17m,Floating Fish Feed Extruder Machine 17*1.2*2.2m |
||
Floating Fish Feed Extruder Machine Fish Feed Making Machine Pet Feed Production Line
Floating fish feed machine is widely used for producing grains into high-grade aquatic feed pellets for fish, catfish, shrimps, crab etc. The puffing fish feed pellets can float on the water surface without dissolution for over 24 hours. According to your requirement and production scale, With different moulds, the machine can produce different diameter food, from 1mm to 10 mm. The food can meet different stage fish.
Machine parameters
| Model |
Installed Power (kw) |
Power Consumption (kw) |
Capacity (kg/h) |
Dimension (m) |
| 65 processing line | 74 | 52 | 120-180 | 17*1.2*2.2 |
| 70 processing line | 95 | 70 | 200-300 | 20*1.5*2.2 |
| 75 processing line | 110 | 82 | 250-400 | 26*1.5*2.2 |
| 85 processing line | 139 | 104 | 400-800 | 28*3.5*4.3 |
| 90 processing line | 132 | 75 | 800-1200 | 28*3.5*4.3 |
| 95 processing line | 165 | 90 | 1500-2000 | 35*3.5*4.3 |
| 120 processing line | 469 | 380 | 2000-2500 | 45*20*22 |
| 135 processing line | 712 | 570 | 3000-3500 | 50*20*25 |
Equipment list in the pet feed production line:
mixer→screw conveyor→twin screw extruder→air conveyor→dryer→hoister→flavoring drum and oil sprayer→cooling machine→packing machine
Main Features:
1). Our processing line adopt international advanced technology, the pellets size are very even.
2). we can adjust the cutter speed and the dies to get the different diameter and the length product
3). The Electric heating device system can control the temperature accurately
4). High temperature and high pressure can kill the salmonellosis andbacterial infections.
5). This line can produce high-protein dog food.
6). This line only need three workers.
Work principle of Floating Fish Feed Pellet Machine
After the material is sent into feeding device, they will be pressed by the screw shaft with high pressure and temperature which makes the raw material fully cooked and sterilized. Then the pressed material will be formed into pellets by shaping mould. You can change different moulds to make pellets with different diameters. After that a cutting device will cut the formed pellets into different length as required.
Advantage of Floating Fish Feed Pellet Machine
1. The machine not only can product floating fish feed, but also can product other pet feed, change mould is ok.
2. The finished pellets can keep floating for 3-15 hours without pollution to water.
3. High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and also makes the pellets easily to digest
4. The cutting device can be adjusted to make pellets of different length.
5. Floating fish feed machine can make pellet from dia.1.0mm-20mm just by changing the mold.
Our Service
1.) New production techniques and formulas;
2.) Provide 1 year complete warranty and life-time maintenance service.
