1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m

I'm Online Chat Now

1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m

1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m
1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m 1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m 1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m 1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m

Large Image :  1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: 65,70,75
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $15,000.00/Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month

1.5cm Dia Floating Fish Pet Feed Production Line Extruder Machine 17*1.2*2.2m

Description
Name: Floating Fish Feed Extruder Machine Fish Feed Making Machine Pet Feed Production Line Condition: New
Dimension(l*w*h): 17*1.2*2.2m Heating Source: Electricity, Gas, Diesel, Steam
Power(w): 74KW Warranty: 1 Year
Capacity: 120-3500kg/h Weight: 380 Kg
High Light:

Pet Feed Production Line 1.5cm dia

,

floating fish feed production line 17m

,

Floating Fish Feed Extruder Machine 17*1.2*2.2m

Floating Fish Feed Extruder Machine Fish Feed Making Machine Pet Feed Production Line



Floating fish feed machine is widely used for producing grains into high-grade aquatic feed pellets for fish, catfish, shrimps, crab etc. The puffing fish feed pellets can float on the water surface without dissolution for over 24 hours. According to your requirement and production scale, With different moulds, the machine can produce different diameter food, from 1mm to 10 mm. The food can meet different stage fish.



Floating Fish Feed Extruder Machine Fish Feed Making Machine Pet Feed Production Line



Machine parameters

Model

Installed Power

(kw)

Power Consumption

(kw)

Capacity

(kg/h)

Dimension

(m)

65 processing line 74 52 120-180 17*1.2*2.2
70 processing line 95 70 200-300 20*1.5*2.2
75 processing line 110 82 250-400 26*1.5*2.2
85 processing line 139 104 400-800 28*3.5*4.3
90 processing line 132 75 800-1200 28*3.5*4.3
95 processing line 165 90 1500-2000 35*3.5*4.3
120 processing line 469 380 2000-2500 45*20*22
135 processing line 712 570 3000-3500 50*20*25



Equipment list in the pet feed production line:

mixer→screw conveyor→twin screw extruder→air conveyor→dryer→hoister→flavoring drum and oil sprayer→cooling machine→packing machine



Main Features:
1). Our processing line adopt international advanced technology, the pellets size are very even.
2). we can adjust the cutter speed and the dies to get the different diameter and the length product
3). The Electric heating device system can control the temperature accurately
4). High temperature and high pressure can kill the salmonellosis andbacterial infections.
5). This line can produce high-protein dog food.
6). This line only need three workers.



Work principle of Floating Fish Feed Pellet Machine

After the material is sent into feeding device, they will be pressed by the screw shaft with high pressure and temperature which makes the raw material fully cooked and sterilized. Then the pressed material will be formed into pellets by shaping mould. You can change different moulds to make pellets with different diameters. After that a cutting device will cut the formed pellets into different length as required.



Advantage of Floating Fish Feed Pellet Machine

1. The machine not only can product floating fish feed, but also can product other pet feed, change mould is ok.

2. The finished pellets can keep floating for 3-15 hours without pollution to water.

3. High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and also makes the pellets easily to digest

4. The cutting device can be adjusted to make pellets of different length.

5. Floating fish feed machine can make pellet from dia.1.0mm-20mm just by changing the mold.



Our Service

1.) New production techniques and formulas;
2.) Provide 1 year complete warranty and life-time maintenance service.
