0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed

I'm Online Chat Now

0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed

0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed
0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed 0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed 0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed 0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed

Large Image :  0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: MK60
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $15,000.00/Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month

0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed

Description
Name: Aquarium Soybean Protein Snack Food Mill Pellet Processing Pet Feet Production Line Condition: New
Dimension(l*w*h): 1251*610*822mm Heating Source: Electricity, Gas, Diesel, Steam
Power(w): 34KW Warranty: 1 Year
Capacity: 120-151kg/h Weight: 245 Kg
High Light:

0.6mm dog food production line

,

34KW cat food production line

,

dog food production line 12.5*0.6*0.8m

Aquarium Soybean Protein Snack Food Mill Pellet Processing Pet Feet Production Line



This Aquarium Soybean Protein Snack Food Mill Pellet Processing Pet Feet Production Line can be used to produce pet food pellets, the pellets size can be changed by adjusting the extruder dies, Meanwhile this line can used to produce dog food, cat food by change some place. You can buy one whole line to make fish food and dog cat food together.

0.6mm 34KW Cat Dog Food Production Line 12.5*0.6*0.8m High Speed 0

Flow of chart:
Mixer -Screw conveyor -Twin-screw extruder -Eelevator-Dryer-Hoister -Flavoring line -cooling conveyor.


Aquarium Soybean Protein Snack Food Mill Pellet Processing Pet Feet Production Line can make kinds of feed, such as food fish, catfish, shrimps, crab, etc. the fish pellet made by the machine can float on water more than 24 hours. Gelatinization degree can reach 90%, enhance the output of fodders, it is suitable for making floating feed, pet food, fish fodder. The diameter of particle is 0.6-16mm. Promising fodder output evenly and continuously.



Parameters of Pet Feet Production Line:

Model SLG65 SLG70 SLG85 SLG95
Install Power 65KW 110KW 190KW 300KW
Consumption Power 42KW 77KW 133KW 210KW
Output 120-150KG/H 220-260KG/H 500-600KG/H 900-1000KG/H
Dimension 19000×1300×2200mm 22000×1300×2200mm 30000×1300×2500mm 38000×1300×3000mm



Main Parts of Twin screw extruder with electricity heating system:
a. The screws are made by alloy steel (38CrMoAL) and special craft by nitriding process, The HRC hardness is around 60---62, it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.
b. The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.
c. The gearbox has automatic lubrication function, with extends gear life.
d. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
e. SIEMENS(CHINA) brands electronic parts used in the controller box, make sure the extrusion process perfect.
f. Main Motor from SIEMENS(CHINA), ensure its powerful extrusion and excellent performance.



Raw materials for Animal food pellet:
For example,Most of pet food pellet inculding animal protein and plant protein, Plant protein adopts corn flour,rice flour,wheat flour,soybean flour,peanut cake powder..Animal peotein adopt meat meal, shrimp meal,crab meal, sleeve-fish meal ,bone power,fresh meat paste,chicken paste and so on.you can add other ingredient according to the local fish live require.
Cat food you should add sea animal powder...
Dog food you should add bone powder, meat powder..
You should change some raw material percent according to the animall require!

Normally, according to our experience, a space with 24×4×3M is enough for our whole production line. But consideration of raw material and final production warehouse, dressing room, pre-mix preparation room etc. You can design it according to your requirement.
Operator Needed: 3-5 Normally, one manager, two operator and one technician
Power Consumption: 76.0kw
Guarantee time: one year



We provide Turnkey Project
a. Provide factory layout according to your factory size in advance.
b. Provide the recipe when your esteemed company cooperate with us.
c. Before place the order, we invite you to visit us and make demonstration for you in workshop
d. Before delivery the machines, we invite you to inspect all the machines.
e. Installation and commissioning in your factory for 15days
