Product Details:
|
| Name: | Mini Chicken Cattle Animal Feed Food Pellet Making Machine Poultry Feed Pellet Mill Pelletizer Machine | Application: | Poultry Farm |
|---|---|---|---|
| Voltage: | 220V/380V/customized | Capacity: | 200KG/H |
| Weight: | 315kg | Dimension(l*w*h): | 130*53*105CM |
| Advantage: | High Efficiency Easy Operation | Final Product: | Feed Pellet |
| Function: | Pellet Processing Machine | Spare Parts: | Flat Die+ Rollers |
| High Light: | chicken feed pellet mill CE ISO,chicken pellet machine antirust,280kg mini floating fish feed machine |
||
1000-1200kg/Hour Shrimp Animal Food Pellet Making Machine Chicken Fish Feed Pellet Machine
The Animal Food Pellet Making Machine uses a template, and the pressure roller is made of high-quality alloy steel after special treatment. The main shaft and the flat mold drive the pressure roller to rotate under the action of friction. The pressure roller and the template produce high temperature to mature the starch, and the protein is denatured and solidified. Under the pressure of the pressure roller The pellets are discharged from the die hole, and the pellets are sent out of the machine through the throwing plate. The length of pellets can be controlled by adjusting the angle of the cutting knife. This machine is mainly suitable for processing various livestock, poultry and aquatic pellet feeds by professional households in small and medium-scale breeding. Farming costs. It can be used to raise rabbits, chickens, ducks, geese, fish, pigs, aquatic products, etc.
The flat die pellet mill works on vertical principle. The raw material is put into the hopper from above, and then it drops down into the pelletizing area. The die is stationery while rollers are rotating. When falling into this area, materials will naturally be compressed into pellet between rollers and die through the die holes.
•1) Feeding way: Ring die pellet mill adopts imperative feeder when making wood pellets, while the flat die can send material into pelletizing chamber smoothly just depending on the material's own weight.
•2) Pressure: The flat die itself doesn't occupy much space, which not only gives more space for rollers, but also reduces friction and prolongs service life.
•3) Output pellet: Ring die has a high rotary speed, thus it may cause damage to pellet easily; while the flat die can ensure the pellets integrity.
Technical data of Animal Food Pellet Making Machine
| Model | Capacity (kg/hr) | Power(KW) | Weight(kg) | Dimension (cm) |
| BH-125 | 80-100 | 3 | 95 | 110*35*700 |
| BH-150 | 110-150 | 4 | 98 | 115*35*80 |
| BH-210 | 200-300 | 7.5 | 280 | 115*45*95 |
| BH-230 | 350-450 | 11 | 300 | 138*46*100 |
| BH-260 | 500-600 | 15 | 315 | 130*53*105 |
| BH-300 | 700-800 | 22 | 600 | 145*62*120 |
| BH-360 | 800-900 | 22 | 795 | 160*67*145 |
| BH-400 | 1000-1200 | 30 | 1000 | 160*67*145 |
Features of Pellet Making Machine Price: Pellet Feed Making Machine
* ring die feed pellet making machine reaches international advanced level; it has the latest technology and low breakdown
rate;
* On the basis of Type A pellet mill, variable speed motor is added to raw material conveying to control the feeding, the
feeding is steady and reliable;
* Drive mechanism adopts high strength belt, with steady running and low noise;
* Drive mechanism adopts high quality bearing to ensure high speed and stable operation;
* Feeding part is equipped with a permanent magnet to remove metallic impurities; this prolongs the service life of main
parts and meanwhile reduce the use of auxiliary equipment.
* Convenient operation, reliable sealing, high production rate, low power consumption, low labor strength.
FAQ
Q: Why choose us? A: For many years, our company adhere to the business philosophy “Quality first, integrity innovation, meet customer demands”. Our company and products have received good reputation and be recognized by customers in domestic and abroad. The products with competitive price have been exported to the United states, Russia, India, Japan, Brazil, France, Middle Eastern countries and southeast Asian countries etc.
Q: Are you trading company or manufacturer? A: Yes, we are factory, all machine is made by ourselves and we can provide customize service according to your requirement. We have production line, R&D department, QC department, sales and after-sales service department and so on Q: How long is your delivery time? A: Generally, it is 1-3 day if the goods are in stock. And it is about 3 to 7 days if the goods are not in stock, it depends on your quantity requirement.
Q. Is this machine easy to use and if we have no experience to use it, can we operate it well? A. Yes, our machine is intended to designed easier operation for you. We can provide machine videos or pictures to you; it can help us how to operate it well.
Q: What about your warranty? A: Our warranty is 1 year; The machine parts can be replaced for free within 1 year if quality defect (Excluding man-made damage). Q: Does your company accept OEM? A: Yes, we accept OEM orders if we have quantities order.
Q: What can you provide after service? A: Professional technical team and after-sale service team always beside you if you have any questions.
