Product Details:
|
| Name: | Poultry Feed Pellet Machine | ITEM: | Pellet Making Machine |
|---|---|---|---|
| Weight (KG): | 350 | Driven Type: | Motor ,diesel Engine,PTO |
| Pellet Diameter: | 2-12 Mm (can Be Selecation) | Warranty: | 1 Year |
| Raw Material: | Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton | Show Room: | Viet Nam, Indonesia,China |
| Key Selling: | Easy To Operate | Power Supply: | Diesel Engine/gasoline/motor/PTO Driven |
| Certificate: | CE | Dust Remove System: | Cyclone And Bag Dust, To Remove The Dust |
| Capacity: | 800-1000kg/h | ||
| High Light: | CE Biomass Wood Pellet Mill,800kg/H Wood Pellet Mill |
||
wood pelets line wood pellet machine biomass pellet mill line price wood pellet mill
▶ Frequency Conversion Feeder:
The feeder is driven by a variable frequency motor, and the feeding speed is automatically adjusted by inductive load voltage, which saves energy and ensures the highest efficiency.
▶ Anti-cake Device:
Prevent the formation of agglomerates that are not easy to fall into the feeder to ensure the feeding efficiency.
▶ Forced Feeder:
Located in front of the pelletizer chamber, lighter raw materials can enter the pelletizing chamber smoothly and quickly to ensure the granulating efficiency.
Feature of biomass pellet mill line price
1.Vertical hopper:
This design can avoid the raw material be stuck in granulating room
2.Cooling system:
As the pelletizing process will generate high temperature, it will lower the service life of die and bearing.Cooling system are considering this situation and avoid it happened.
3.Double-layer dies:
This design increase the efficiency of pellet making,reduce clients cost.
4.Siemens frequency conversion motor:
Sweden famous brand.
5.SKF bearing:Sweden famous brand, High precision, high speed, low noise, long span life.
6.Unique automatic lubricating system:Which lubricate the bearing, dies and rollers ,increase the produce efficiency and reduce energy consumption.It can work continuous 20 hours without stoping.
7.Roller High alloy steel, roller wrap adopt heat treatment
8. Mold: Stainless steel
9. heavy and stable machine foundation
10. Surface adopt stoving varnish painting
| Model |
Capacity (kg/h) |
Power (kw) |
Specification (mm) |
Weight(t) |
Dimension (mm) |
| RKL-250 | 100-200 | 15 | 4-6 | 0.5 | 1400*600*1000 |
| RKL-280 | 150-250 | 22 | 4-6 | 0.65 | 1760*670*1600 |
| RKL-300 | 100-300 | 30 | 4-8 | 0.76 | 1860*670*1600 |
| RKL-350 | 300-600 | 37 | 4.5-10 | 2.2 | 1900*850*1750 |
| RKL-400 | 500-800 | 55 | 4.5-10 | 4.3 | 2300*1100*1900 |
| RKL-550 | 1000-1500 | 90 | 4.5-12 | 5.5 | 2350*1100*2050 |
| RKL-800 | 1500-2500 | 160 | 4.5-12 | 6.8 | 3200*1235*2700 |
| RKL-1200 | 3000-5000 | 320 | 4.5-15 | 19 | 3800*1700*4200 |
How Does Assure The Quality Of The Biomass Wood Pellet Machine?
▶Pelletizing Chamber:
Provide space for granulation. The main components are roller assembly and ring die, bearing, chammer cover, etc.
The pelletizing chamber is equipped with a cutter adjusting handle, which can easily adjust the distance between the cutter and the ring die, thereby controlling the length of the pellets.
Equipped with an observation hole, you can observe the cutting of pellets by the cutter at any time, and control the production situation.
▶Press Roller Assembly:
The roller assembly is made of 42CrMo material: Compared with stainless steel and other alloy materials, it is more
wear-resistant, ensuring long-term stable operation of the machine.
Removable design: only need to replace the pressure roller shell to repair the pressure roller assembly, after a long time of work.
▶Stainless steel body:
The biomass pellet machine uses a stainless steel body to prevent corrosive substances such as moisture in the raw materials from corroding the pellet machine during long-term operation.
▶Siemens Motor:
The main motor of pellet machine adopts Siemens motor. The 8-level high-torque, high-quality, stable-running motor provides power guarantee for the long-term stable operation of the pellet machine.
