China factory Machines for processing wood shavings making machine wood chipper

I'm Online Chat Now

China factory Machines for processing wood shavings making machine wood chipper

China factory Machines for processing wood shavings making machine wood chipper
China factory Machines for processing wood shavings making machine wood chipper

Large Image :  China factory Machines for processing wood shavings making machine wood chipper

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: BS-420,BS-1000,BS-800,BS-600
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $950.00 - 3900.00/ Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

China factory Machines for processing wood shavings making machine wood chipper

Description
Name: CE Certificate Tunisia Bulk Pine Aspen Wood Shavings For Horse Animal Bedding Machine Wood Shaver Power(w): 11-55kw
Weight: 500kg Voltage: 380v ,Customized
Dimension(l*w*h): 1200*500*700mm Capacity: 300-2000kg/h
After-sales Service Provided:: Online Support Package: Wooden Case

China factory Machines for processing wood shavings making machine wood chipper



Introduction



1. wood shaving machine is used for Particle board, paper producing, wood pulp paper making, also can be used as biomass fuel, warm material in feed industry.

2.The machine can shave wood logs, tree branch,waste wood etc. into wood shavings.

3.The wood shaving thickness can be adjusted.

China factory Machines for processing wood shavings making machine wood chipper 0

China factory Machines for processing wood shavings making machine wood chipper 1

  Type     Knives qty    Input size(mm)    Cutter dia(mm)    Blade size(mm)    Output(t/h)    Spindle speed(r/min)    Power(kw)          Size(mm)
420 4 160*155 424 90*60*8 0.8-1.5 2600 7.5-11 1200*550*750
500 4 210*180 510 120*70*8 1.2-2.0 2400 18.5-22 1500*640*820
600 4 235*200 600 150*70*8 1.8-2.5 2200 22-30 1600*700*1050
700 4-6 230*200 600 180*70*8 2.5-3.5 2000 30-37 1850*830*1050
900 8 280*290 750 150*100*10 5.5-6.5 1500 55-75 2000*870*1500
1000 8 280*290 750 150*140*10 6-7 1500 75-6 1180*1100*940
1200 8 390*385 1000 190*140*12 7-8.5 1200 90-6 1430*1500*1200
1500 8 425*500 1160 230*140*14 9-11 1000 110-6 1650*1750*1400
1800 12 530*560 1300 150*140*14 11.5-14 950 132-6 2050*1850*1620




Product Description



1. Features

This type of wood shaving machine made by us is energy-saving type and easy to operate.It is designed and developed according to industrial requirements.It belongs to wood crushing and pulverizing machine. It is finely processed, high efficiency and environmental protection type. It is optional for electricity and diesel so it can meet buyers’ different requirements.

2. The working principle

Wood Shaving Machine is used to make wood shavings. The different size of final product can be adjusted by tuning the cutter and changing the sieve. the raw material gets into the machine from feeding port, through the cutter to the crushing room, under the effect of the mutual striking hammers, the material is being crushed.

3. The main purpose

The wood shaving machine can make the wood shaving for log .branch and plate.the thickness of wood shaving can be adjusted.

we have four types for you choose,you can depend on your needs and output requires to order,if you interest ,please contact me at any time .



China factory Machines for processing wood shavings making machine wood chipper 2



China factory Machines for processing wood shavings making machine wood chipper 3

China factory Machines for processing wood shavings making machine wood chipper 4


FAQ

1. What is the voltage/phase for this machine?

-- We normally make voltage into 220V/50HZ/Single phase or 380V/50HZ/Three Phase.But it can be made accourding to clients' demand, like 110V/60HZ/Three phase.

2. What kind of packing box is?

-- we pack machines in a standard exporting plywood case, no vermin,germs.

help get better protection while transporting.

3. How long is the guarantee?

-- we promise guarantee as one year for non-human damage factor.

4. How should I do if meet some trouble while using?

-- don't worry about that. we are always be pleased to provide using support to

clients. we can take a video for showing how to resolve the problem. and write

detail resolution to you.

5. What's the payment mode?

--T/T,L/C,Western Union or MoneyGram.



Package

1.wood shaving machine italy will be packed in standard and quantities boxes ,the production will have a safe and complete journey from our factory to your place.

2.Packaging details standard export wooden case or in container.



Shipping

1.We will serve your shipping method about ocean transport ,air lift ,freights and so on.

2.The delivery time is usually 7-15 working days upon receipt of your payment.
