Product Details:
|
| Name: | Livestock Feed Grain Crushers Grass Grinder Machine Hammer Mill Machine | Power: | 3kw |
|---|---|---|---|
| Warranty: | 1 Year | Condition: | New |
| Type: | Hammer Mill | Capacity(t/h): | 50-2000kg/h |
| Dimension(L*W*H): | 700*500*600 | Weight: | 2900 Kg |
| High Light: | livestock feed grinder 3000w,grass grinding machine 3kw,MIKIM grain crusher machine |
||
Livestock Feed Grain Crushers Grass Grinder Machine Hammer Mill Machine
Livestock feed grain crushers grass grinder machine hammer mill is a kind of hammer mill equipment which mainly depends on the hammer to smash the material, shredded material can be directly with grits, rice bran, bean cake and other feed for poultry animals eat, widely used in feed factory, farm, and individual agricultural households.
Specifications of this series hammer mill:
| Model | Power(kw) | Size(mm) | Weight(kg) | Capacity(kg/h) |
| 260 | 3 | 700*500*600 | 76 | 50-200 |
| 320 | 3 | 700*600*700 | 85 | 100-300 |
| 360 | 4 | 700*600*800 | 90 | 150-400 |
| 400 | 5.5 | 900*700*1000 | 120 | 200-500 |
| 420 | 7.5 | 950*800*1100 | 140 | 300-600 |
| 500 | 15 | 1100*900*1200 | 200 | 400-700 |
| 600 | 30 | 1900*1200*1900 | 500 | 600-1000 |
| 800 | 37 | 2500*1500*1300 | 800 | 1000-2000 |
Capacity for different grain materials
| Capacity(kg/h) | 320 | 360 | 400 | 420 | 500 | 600 |
| Corn | 300-350 | 400-600 | 500-750 | 800-1000 | 1000-1500 | 2000-3000 |
| Corn stalk | 100-150 | 150-200 | 200-300 | 200-400 | 350-600 | 1000-2000 |
| Bean stalk | 150-200 | 200-300 | 250-400 | 250-500 | 500-800 | 1000-1500 |
| Sweet potato stalk | 150-200 | 200-300 | 250-400 | 300-500 | 400-700 | 1000-1200 |
| Cavings | 100-150 | 150-200 | 200-300 | 200-400 | 350-600 | 800-1500 |
Main Features
This Feed mill is mainly composed of frame, shell, coupling, hammer, screen, pulley, electric frame, motor, feed foil, etc.The structure is simple and reasonable, hammer is made of manganese steel with high wear resistance,and the material size of the finished product can be adjusted according to the size of sieve mesh, power consumption is small, service life is long, and the production can be moved, which is very convenient.
Working principle:
The machine is composed of feeding hopper, upper and lower body, rotor, screen, fan, feeding tube, etc. Users can be equipped with storage bags or storage bin according to their own needs. The material is broken by a high-speed rotating hammer after entering into the crushing chamber. The pulverized powder is quickly transported to the storage bag or silo by the centrifugal pressure of the rotor and suction of the fan.
Pre-Sales Service
1. According to the customer’s needs,we will give a detail suggest.
2. Provide professional machine design with our engineer
3. Offer various payments to avoid financial issues
4. Be ready to your visiting.
After-Sales Service
1. If any parts are found defective in quality in the first year, we shall replace it free-of-cost.
2. After one year, parts can be replaced on favorable payment basis.
3. If you have any question, please contact us freely. We will try our best to help you to solve the problem.
