25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine

I'm Online Chat Now

25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine

25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine
25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine 25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine 25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine 25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine

Large Image :  25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: 420,500,700,800,1000
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $500.00 - 910.00/ Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine

Description
Name: Portable Hammer Mill Machine Crusher Wood Shredder Biomass Shredding Machine Voltage: 380V
Warranty: 1 Year Blade (sheet): 4
Type: Hammer Mill Capacity(t/h): 300-12000kg/h
Dimension(L*W*H): 1500*700*1000mm Advantage: Easy Operation
High Light:

25*2CM portable hammer mill

,

Hammer Mill Machine 55KW

,

portable biomass shredding machine

Portable Hammer Mill Machine Crusher Wood Shredder Biomass Shredding Machine



The Hammer mill has a compact structure layout. All material thickened steel plate parts are wear-resistant, high quality, hydraulic forced reduction, stable performance, high safety, and high production efficiency. Logs, branches, trunks, reed poles, leftovers, etc Chips of a kind of wood material. Complete functions, strong crushing ability, and good crushing effect.



25*2cm Portable Hammer Mill Machine 55KW Biomass Shredding Machine 0



Model
420
500
700
800
1000
1200
1500
1800
Blade
(sheet)
4
4
4
4
4
4
4
4
Feed diameter
(mm)
150*150
180*200
230*230
250*250
270*270
330*330
420*400
520*520
Spindle speed
(r/min)
2600
2600
2400
2000
2000
1500
1200
1200
Motor
(kw)
7.5/11
18.5
37
45/55
45/55
75/90
110/132
132/160
Diesel engine
(horsepower)
18
28
50
80
80
120
160
200
Yield
(kg/h)
300-500
500-600
800-1500
1200-2000
1500-3000
3000-7000
3000-10000
3000-12000
Weight
(kg)
280
380
520
750
1080
1280
3100
3800



Hammer mill machine structure and crushing principle:
1. The wood flour machine is composed of three parts: the body, the middle body and the lower body.
2. The crushing knife is composed of a 7-type knife, a 1-type knife and a centrifugal knife.
3. The auxiliary machine is composed of a fan, a powder collector and a dust collector.
4. The main machine's crushing chamber adopts 7-type knife, one-type knife and centrifugal knife. There are coarse crushing, fine crushing and centrifugal reciprocating crushing. The motor drives the rotor of the crusher to run at high speed, so that the machine generates high-speed airflow to produce high-strength crushing materials. Impact force, compression force, cutting force, friction force, to achieve a unique crushing function.
5. During the cutting and crushing process of the three kinds of blades, the rotor generates a high-speed airflow that rotates with the direction of the blades. The materials are accelerated in the airflow and repeatedly impacted and cut friction. At the same time, they are subjected to three kinds of crushing effects. The crushed materials enter the analyzer with the airflow. Analysis, due to the centripetal force of the airflow when it is subjected to the centrifugal force of the analyzer rotor, when the centrifugal force is greater than the centripetal force, the fine particles will enter the powder collector with the airflow for collection, and the coarse particles will enter the centrifugal rifle crushing chamber and continue to be crushed until you are satisfied. The fineness.



Notice:

And we also have other fertilizer processing equipments,like compost turner,crushing equipments,mixing equipments,drying and cooling machines and auxiliary equipments.

The different BB fertilizer,organic fertilizer and compound fertilizer production line and water-soluble fertilizer fermentation equipment can be provided too.



Pre-sale Service:

1. Offering comprehensive technical and business consultation services;
2. Proposing the most suitable scheme and equipment for our clients;
3. Designing and fabricating targeted products according to the special requirements of clients;
4. Training periodically high qualified service technician.
5. Free CAD design: if you can provide the material, your aim capacity and your factory information, we can make a free CAD design for you.

After-sales Service:
1. Highly inspecting equipments in every working procedure, quality comes first;
2. Fast & Safe Delivery;
3. Assisting our clients for foundation construction of equipments;
4. Dispatching engineers to install and debug equipments;
5. Training the first-line operators on site;
6. Regularly visit clients to solve production problems Providing life-long maintenance service
7. Providing technical exchanging.
