|Name:||Straw Pellet Making Machine||ITEM:||Pellet Making Machine|
|Weight (KG):||850||Driven Type:||Motor ,diesel Engine|
|Lubrication System::||Use Recycling Lubrication Oil||Pellet Diameter:||3~25 Mm (can Be Selecation)|
|Warranty:||1 Year||Raw Material:||Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton|
|Die Material:||Alloy Metal 3CR13||Show Room:||Viet Nam, Indonesia|
|Key Selling:||Easy To Operate||Voltage:||Customized|
|Certificate:||CE ISO||Dust Remove System:||Cyclone And Bag Dust, To Remove The Dust|
|Capacity:||600-800kg/h||Application:||Making Wood Pellet Fuel And Poultry Feed|
sawdust pellet making machine alloy metal,
4kw Wood Pellets Machine,
120kg/ h straw pellet making machine
straw pellet making machine sawdust pellet making machine alloy metal
1. Pellet press can make all kinds of bio-mass material to be solid pellets which is
for burning fuel or animal feed.
2. We have new improved models for wood pellet making. Specially design and
improved machines according to European standard, with closed house to cover
motor, CE electrical parts & insolated protective plate for the electrical panel.
3. Our pellet mill also can process all kinds of sawdust. Paddy Straw, Sunflower
Stalk, Forestry Wastes, Wood Chips, Chemical And Many Other Wastes Or Solid Powder Material.
4. Our pellet mill have CE certificate, Which all parts can meet EU standard.
Advantages of Animal Feed Pelletizer:
Simple in structure, easy in operation and service, safe in solidity, small in volume. And light in weight etc.
No special training needed and operation available through manual, The animal feed making machine accepts dry materials. The moisture of raw materials is not less than the national standard of 13%. Differential and universal joint driver is adopted.
Both the motor or diesel engine are OK. The use of unique technology can complete the whole process of low-temperature drying, cooling and screening in one passage.
The results show that cattle feed making machine is extensively applied to use of chicken feed pellet making machine in animal husbandry,
The animal feed making machine is the ideal choice for making animal food like duck feed, chicken feed, fish feed and so on. This process is easy in operation and low in cost with a high survival rate of biomass microorganism bacterium >90%.
|wood pellet capacity||40-60kg/h||90-120kg/h||100-150kg/h||150-200kg/h||200-300kg/h||300-400kg/h|
|feed pellet capacity||60-100kg/h||150-220kg/h||200-300kg/h||300-400kg/h||400-600kg/h||600-800kg/h|
Application of the animal feed pellet press:
Our Home Use Feed Processing Machine can work on crushed corn, bean, bean pulps, straw, grass, chaff etc into feed pellets for rabbits, pigeon, layer chicken, duck, broiler, pig and so on.
You can make 2-8 mm diameter animal feed pellets. Such as 2-4mm diameter chick feed pellets and pig feed pellets.2-5mm rabbit feed pellet, 4-8mm cattle or sheep feed pellets. he length of feed pellets can be adjusted.
Details of sawdust pellet machine wood pellet making machine price
(1) The speed of our sawdust pellet machine wood pellet making machine price :
The motor speed is fixed, all of the particles machine motor speed is 1400RPM.
Our pellet machine's speed is 200-300RPM, inside the machine with a complex reducer, which can change the E-motor speed and the main shaft speed.
(2) Fuel consumption of our sawdust pellet machine wood pellet making machine price
Diesel engine pellet machine's fuel consumption: For 8Hp, it is 1.23L/H.For 15Hp, it is 2.31L/H.For 22Hp, it is 3.36L/H.
For 35HP, it is 5.39L/H. 7.5HP gasoline guzzling about 1.2L / Hour.
(3) Wheel of our sawdust pellet machine wood pellet making machine price :
Motor-driven particle machine not with wheels, diesel particulate gasoline powered machines with wheels.
(4) Transmission of our sawdust pellet machine wood pellet making machine price
Motor is shaft drive. Diesel shaft drive.
(5) Package of our sawdust pellet machine wood pellet making machine price
Packaging is plywood wood care, non-wood, fumigation.
(6) Spare parts and lubrication of our sawdust pellet machine wood pellet making machine price
The machines' spare parts case takes a Grease gun, used to add lubricating oil pressure roller and spindle bearings, where oil useLithium-based lubricants: GB7324-94.
(7) Emergency stop switch of our sawdust pellet machine wood pellet making machine price
If you need, we can add the emergency stop switch for you.
(8) 260,300,360 ,400 is three pressure rollers. At the time of installation, the gap between the pressure roller and the matrix (Die) needs adjusted 0 ~ 0.5mm. (The thickness of a sheet of A4 paper is about 0.1mm) smaller the gap, the material will be sooner, butthe disc and the pressure roller loss is also faster.
(9) Star-delta starter of our sawdust pellet machine wood pellet making machine price
It is main used to protect the motor.
(10)pellet's length of our sawdust pellet machine wood pellet making machine price
The pellet isn't fixed, it is 2-5cm.But you can adjust the spout's screw to change the position of the blade, it could also conteol the pellet's length.
