1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die

I'm Online Chat Now

1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die

1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die
1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die 1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die 1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die 1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die 1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die

Large Image :  1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: KL-560
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $9000.00 / Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month

1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die

Description
Name: Wood Sawdust Pellet Machine ITEM: Wood Biomass Pellet Machine
Weight (KG): 2000 Die: Double Layer, Both Can Be Used
Driven Type: Motor ,diesel Engine Lubrication System:: Use Recycling Lubrication Oil
Pellet Diameter: 3~25 Mm (can Be Selecation) Warranty: 1 Year
Raw Material: Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton Die Material: Stailness Steel 4Cr13
Show Room: Viet Nam, Indonesia Key Selling: Easy To Operate
Voltage: Customized Certificate: CE ISO
Dust Remove System: Cyclone And Bag Dust, To Remove The Dust Capacity: 1000-1500kgs/h
Application: Machine Make Biomass Fuel Pellet
High Light:

1.5t/ h alfalfa pellet machine

,

alfalfa pellet mill 9000W

,

90KW ring die pellet machine

Biomass Wood Pellet Machine also called bio fuel pelletizer, pellet granulator, fodder pellet mill, briquette pelletizing machine (machine de fabrication de la paille, pelletizadores, peletizadora pellet). The flat die has only vertical type, while the ring die (Circular Mould Ring Matrice - 2 layers matrix) have vertical and horizontal structure, it is not hot press machine, but cold press machine. The automatic multipurpose pellet machine production factory is a complete plant project which can processing large range of materials and producing (manufacturing) biofuel pellets. High capacity manufactures are making pellets for power plant, home use, industry use.

Applicable material
Applicable to: rice husk, sunflower seed shell, peanut shell and other melon shell; branches, trunks, bark and other wood scrap; all kinds of crop straw, rubber, cement, gray Slag and other chemical raw materials, etc.

1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die 0

How to make pellet
1. Use Wood Chipper, Wood Crusher to make wood logs, chips (or other materials) smaller.
2. Use Dryer (rotary drum dryer / Air-flow dryer) or add water to the sawdust(or other materials) till its moisture content between 8-15%, which is the best moisture content for pelletizing.
3. Put the sawdust into the pellet machine gradually. Large scale pellet production need a screw feeder to make sure stable feeding of raw material.
4. After pelletized, the pellets are of high temperature that is not suitable for direct packing. So they should be cooled by pellet cooler.
Then, pellets go through a vibrating sieve, where good pellets will be left, while broken ones or powder will be collected for reproduction.
5. After all the above procedures, pellets can be packed with a pellet packing machine.

Model Power
(kw)
Capacity for
wood pellets(kgs/h)
Weight of the
machine(kgs)
Dimension of the
machine (mm)
KL-560 90+1.5+0.37+1.5 1000-1500 6100 2600x1300x2300
KL-850 220+3+0.37(0.55)+2.2 2000-3000 14500 3300x1400x3100
KL-920 315+5.5+0.55+1.5+2.2 3000-4000 18000 3800x1680x3400

1.5t/ H Alfalfa Pellet Machine Mill 90KW Ring Die 1

Different structures of pellet mills
Wood Pellet Mills differ from typical pellet mills in several primary ways. They are much lower geared to increase available torque and as a result they spin more slowly. Thus they are less productive when making pellets out of hay or grain. If you want to make wood pellets this is the right type for you. They are capable of very large amounts of production and they don't wear out as quickly as flat plate mills. They are quite a bit heavier than flat plate mills.

Advantages of ring die pellet mill over Flat Die Pellet Mill
1. It is a large pellet mill. So it is mostly used in industrial pellet production.
2. The pellet mill is especially suitable for processing wood and palm fiber. So many investors with large quantity of wood or palm fiber material choose ring die pellet mill instead of flat die pellet mill.
3. A set of ring die pellet mill has relatively longer service life compared to flat die pellet mill.
4. The pellets made by ring die pellet mill have larger density and smoother surface since ring die pellet mill has higher pressure.
If you want to produce pellets in large scale, ring die pellet mill is your best choice.

For more information, please contact with our service staff.
