Product Details:
|
| Name: | Vertical Ring Die Pellet Machine | ITEM: | Fuel Pellet Mill |
|---|---|---|---|
| Weight (KG): | 2000 | Die: | Double Layer, Both Can Be Used |
| Driven Type: | Motor ,diesel Engine | Lubrication System:: | Use Recycling Lubrication Oil |
| Pellet Diameter: | 3~25 Mm (can Be Selecation) | Warranty: | 1 Year |
| Raw Material: | Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton | Die Material: | Stailness Steel 4Cr13 |
| Show Room: | Viet Nam, Indonesia | Key Selling: | Easy To Operate |
| Voltage: | Customized | Certificate: | CE ISO |
| Dust Remove System: | Cyclone And Bag Dust, To Remove The Dust | Capacity: | 800-1000kg/h |
| Application: | Machine Make Biomass Fuel Pellet | ||
| High Light: | eucalyptus Wood Pellets Machine,vertical ring die pellet machine 3000kg/ h,fuel pellet mill 3t/ h |
||
Vertical Ring Die Pellet Machine is a new biomass fuel production machinery by processing scrap from forest and agricultural waste like eucalyptus, pine, birch, poplar, fruit and agricultural straw, bamboo. Compared with the old machine, it absorbed the essence of horizontal ring die and flat die pellet machine, solved the insufficient pressure, die crack problems of horizontal ring die pellet machine, and overcame the small capacity, high failure rate of flat die pellet machine.
| Model | Power (kw) |
Capacity for wood pellets(kgs/h) |
Weight of the machine(kgs) |
Dimension of the machine (mm) |
| KL-560 | 90+1.5+0.37+1.5 | 1000-1500 | 6100 | 2600x1300x2300 |
| KL-850 | 220+3+0.37(0.55)+2.2 | 2000-3000 | 14500 | 3300x1400x3100 |
| KL-920 | 315+5.5+0.55+1.5+2.2 | 3000-4000 | 18000 | 3800x1680x3400 |
It adopt the large modulus hardened surface helical gearbox, main shaft reinforcement, power output is strong, good stability, low failure rate, low production cost, so it is the first choice machinery for biomass energy industry.
(1) Big Gear Box
The gearbox adopts independent research and development big 3 level drive,module increased , gear strengths increased,carrying more and more ability.The service life increased 8-10 times than the traditional reducer,greatly increase the service life.
(2) Casting material of gearbox with high stability.
Gearbox body is casted. Its advantages has strong,good heat dissipation,low heat deformation, high steady etc. Avoid disadvantages of the bad sealing for welding boby, easily deformation due to high heat,low steady in basis etc.
(3) Parallel vertical installation reduce energy consumption loss.
The motor and main shaft of wood pellet machine supplier are parallel vertical installed , which can reduce energy consumption loss in the process of transmission, more output power, higher transformation of energy efficiency.
application
Biomass pellets are alternative fuels to non-renewable energy sources such as coal, petroleum, and natural gas, which can
save energyand reduce carbon emissions. It is an efficient and clean renewable energy source. They can obtain heat energy
through combustionand are widely used in life heating, power generation and other fields.
FAQ
1.Q: General questions to design the production line for you?
A:1. What is your raw materials? (to confirm mould pressure ratio of machines )
2. What is the moisture content of your raw material?
3. How many output capacity do you want per hour / month/ year?
Note: If the moisture is high, you need a dryer, becuase the suitable moisture content to enter pellet machine is 13-15%. And please provide us above detailed information, then we would design the most suitable production line with reasonble offers.
2. Q: How long is your guarantee?
A: 12 months warranty but except quick wearing parts.
3. Q: Will you send engineers to install the machines?
A: Of course. Our company has professional installation engineers team and specialized after-sale service team. When the machines arrive your factory, we will send our installation engineers to your factory Our engineers will Guide you to install the machines and training your workers how to operate the machines and maintain the machine.
4. Q: Voltage requirement ?
A: Our machines can use 380V, 220V, 240V, 415V, 480V, and 50Hz, 60Hz.
