Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: DF-135,DF-50,DF-40,DF-70,DF-60,DF-90,DF-80
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $1500.00 - 9500.00/ Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

Small Floating Fish Feed Mill Pellet Extruder Machine With Diesel Engine

Description
Name: Producing Animal Feeds Pellets Type: Feed Pellet Machine
Voltage: 380V Dimension(L*W*H): 1450x950x1430mm
Weight: 480 Kg Output: 120-150kg/h
High Light:

Floating Fish Feed Pellet Extruder

,

Diesel Engine Feed Pellet Extruder

Small Floating Fish Feed Mill Pellet Extruder Machine With Diesel Engine

This fish feed pellet extruder machine is suitable for making fish feed and other pet food with different shapes by changing different molds. The molds can be customized according to requirements. The extruded feed pellets produced by this machine are neat and smooth.

Model

Main power

(KW)

Feeding power

(KW)

Cutter power

(KW)

Spiral diameter

(mm)

Productivity

(t/h)

Size

(mm)

Weight

(kg)

DGP40 4.0 0.4 0.4 40 0.03-0.04 1400x1030x1200 240
DGP50 11 0.4 0.4 50 0.06-0.08 1400x1030x1200 320
DGP60 15 0.4 0.4 60 0.12-0.15 1450x950x1430 480
DGP70 18.5 0.4 0.4 70 0.18-0.25 1600x1400x1450 600
DGP80 22/27 0.4 0.75 80 0.3-0.35 1850x1470x1500 800
DGP90 30/37 1.1 1.5 90 0.4-0.45 1900x1500x1600 1200
DGP100 37 1.1 1.5 100 0.45-50 2000x1600x1600 1500
DGP120 55 1.1 2.2 120 0.5-0.7 2200x2010x1700 1850
DGP135 75 1.1 2.2 135 0.8-1.0 2600×2200×1850 2500
DGP160 90 1.5 2.2 160 1.2-1.5 2800x2400x1850 2800

feed pellet machine

Electric start diesel engine: For areas with insufficient power, diesel engines can solve power problems and are easy to use.

Control cabinet: button operation, easy to understand, and master

Upper Feeder: The feeder is of an automatic speed control type, consisting of a hopper, a pusher screw, and an outlet tube.

Pour the mixed raw materials into the feed bin. All-round 360-degree circular stirring. screw pushing into the raw materials, automatic uniform feeding.

Sleeve type extrusion screw device: The extrusion screw is a sleeve type combined structure. The material is pushed from the feed box to the compression chamber from the extrusion screw and is continuously heated by different degrees of extrusion until it is discharged.

Molds: Different feed pellet shapes by changing different molds.

Rotary cutting device: rotary cutting device of variable frequency speed regulation, which can adjust the rotating speed of the blade arbitrarily to control the cutting speed and length.

Motor: The motor controls the feeding and cutting speed.
