Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust

I'm Online Chat Now

Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust

Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust
Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust

Large Image :  Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: MK-50,MK-80
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $2000.00 - 2400.00/ Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust

Description
Name: Fully Automatic Wood Waste Sawdust Screw Briquetting Charcoal Making Machine Type: Screw Briquetting Charcoal Briquette Machine
Warranty: 12 Months Voltage: 380V 50hz
Dimension(l*w*h): 1800*600*1600mm Weight: 600 KG
Diameter Of Briquettes: 50~80mm Customized Spare Parts: Screw Propreller,mold Cyclinder
High Light:

Biomass Waste Briquettes Making Machine

,

Coffee Husk Briquettes Making Machine

Biomass waste coffee husk wood charcoal sawdust wood briquettes making machine for sale

Wood charcoal briquette making machine shows the features of high capacity, low energy consumption, compact and durable. Many performance data such as capacity, wood briquettes density, electricity consumption and wearable degree has reached advanced level. Charcoal briquette machine can be used as charcoal powder briquette machine by replacement of some spare parts. The out diameter of finished briquettes is 50mm/80mm.



Diameter of briquette Motor Capacity Inlet diameter Dimension
50mm 18kw 180-200kg/h ≤5mm 1.7×0.66×1.5m
50mm 22kw 220-300kg/h ≤5mm 1.78×0.66×1.53m
80mm 18.5-22kw 220-300kg/h ≤5mm 1.78×0.66×1.53m


Characteristic:

No binder or noxious chemical need to use.
The humidity of the raw materials is controlled in 8-12%.
Using the advanced Hot air drying system with the perfect performance.
After the processing of High temperature, purification, smoke removing, the carbonizing equipment transforms the semi-finished bio-fuel briquette into a smoke-free, tasteless, non-toxic cleaning carbon.




Working Principle



Briquetting is a process that biomass is compressed under high pressure and high temperature. The machine uses a large screw to grind,compress and extrude the biomass into briquettes.
The self bonding of biomass to form a briquette involves the thermo-plastic flow of the biomass. The natural lining content in biomass is liberated under high pressure and temperature. Lignin serves as the glue in the briquetting process, binds the particles of wood together, thus binding,compressing the biomass to form into high density briquettes.
During this process, no binder need to be used. So the output briquette is a type of clean and green fuel that is ideal for use in furnaces, boilers and open fires.



Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust 0

Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust 1

Biomass Waste Wood Briquettes Making Machine for Coffee Husk Wood Charcoal Sawdust 2
