High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m

I'm Online Chat Now

High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m

High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m
High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m

Large Image :  High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: 9ZC-0.4
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $450.00 / Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m

Description
Name: Silage Chaff Cutter Grass Chopper Hay Cutting Machine Straw Chopper Type: Chaff Cutter
Warranty: 12 Months Voltage: 220v/380v
Dimension(l*w*h): 2200*600*920mm Inlet Type: Automatic Type Or Manual Type For Your Different Choices
Weight: 500 Kg Application: All Kinds Of Grasshum
High Light:

high efficiency silage chaff cutter

,

green fodder cutter 2.2*0.6*0.92m

,

hay silage chaff cutter machine

silage chaff cutter grass chopper hay cutting machine straw chopper



Chaff cutter, as known as forage chopper, agriculture chaff cutter, and feed processing machine, grass cutter and fodder chaff cutter. It is suitable for small and medium-sized farmers and feed processing plants, can also be used to crush paper materials in paper mills. Thismachine can be used to cut all kinds of fresh and dry materials, such as rice straw, wild grass, wheat straw, corn stover, grass, hay, grain straw, peanut seedlings, sweet potato seedlings, etc., for feeding cattle, horses, sheep, Pigs and other livestock, improve the absorption and utilization rate of roughage, and can also be used to return straw to the field. It can be combined with motors, diesel engines, tractors, etc., and is especially suitable for field work.

High Efficiency Hay Silage Chaff Cutter Machine Green Fodder Cutter 2.2*0.6*0.92m 0

Features

1. It is the specific purpose equipment which crumbles big pellets into small ones;

2. Compact structure, evenly size, convenient and quick adjustment. The feeding roll is available to make the feeding smoother. The fineness of finished products is even and crumbled products obtaining rate is improved;

3. Rolls perform differential rotational speed. Pellets are pressed, sheared and torn, thus reaching ideal crumbling effect;

4. Unique feeding hopper and bypass device not only serve to distribute the products, but also serve to bypass the products not requiring crumbling. When bypassing, automatic stoppage is realized through limit switch;

5. V-shape belt driving is adopted. It is stable, low noise, reliable and easy to operate.

Item Name Chaff Cutter
Model No. 9ZP-0.4
Capacity 0.8-1.0tph
Matched Electric Motor Power 2.2/3.0kw
Matched Diesel Engine Power 4.0hp
Matched Gasoline Engine Power 7.0HP
Voltage 220v/Customized
Blades Quantity 4pcs/6pcs
Suitable Raw Material for Processing all kinds of grass, millet straw, rice straw, corn silage, wheat stalk, corn plants, etc.
Cutting Length 10/15mm
Spindle Speed 1060r/min
Inlet Feeding Rollers Rotation Speed 400r/min
Feeding Inlet Width 235mm
Inlet Type Automatic type or Manual type for your different choices
Main Machine Weight 55kg (without driven engine )
Overall Dimension 1300(L)*1150(W)*800(H)mm
Packing Size 600(L)*500(W)*390(H)mm
Electricity Consumption 10 Kw.t/h







FAQ

1. Are you manufacturer?

Yes, we are. Welcome to visit our factory.

2. Can you change the machine voltage as our request?

Yes, we can.

3. How about your after-sales service?

Our engineer can go outside to install and train your workers to operate the full machine line.

4. Warranty time of your machine?

1 year except for consumable spare parts.

5. How about delivery time of your machine?

Generally it needs 5-7 days for big machines or producing line,and it will be much longer but within our negotiated delivery time.





Package

1.wood shaving machine italy will be packed in standard and quantities boxes ,the production will have a safe and complete journey from our factory to your place.

2.Packaging details standard export wooden case or in container.



Shipping

1.We will serve your shipping method about ocean transport ,air lift ,freights and so on.

2.The delivery time is usually 7-15 working days upon receipt of your payment.
