Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings

I'm Online Chat Now

Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings

Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings
Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings
Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings

Large Image :  Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: MK420
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $23,000-25,000 / Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings

Description
Condition: New Model: MZLH558
Main Power(kw): 132 Main Motor Power: 90kw 8 Pole
Force Feeder Power: 1.1kw Feeder Power: 2.2kw
Diameer Of Ring Die: 420mm Applicable Industries:: Manufacturing Plant, Farms, Home Use
Capacity Of Pellet Feed Making Machine:: Capacity Of Pellet Feed Making Machine: Raw Material:: Corn,Soybean,Alfalfa,Grain,Wheat,Sorghum
High Light:

10Ton/ H Poultry Feed Pellet Machine

,

NSK bearings poultry making machine

,

1Ton/ H chicken pellet making machine

1-10 T/H Complete Wood Sawdust Pellet Making Machine Wood Pellet Production Line



Ring die wood pellet mill is specially designed for biomass industrial production of wood pellets. The raw materials are easy to obtain, like groundnut shell, sawdust, paddy straw, wheat straw, palm husk, rice husks, etc and many other agro and forestry wastes. The final pellets can be used for industrial boilers and large power plants as well as home heating.





(1). This pellet machine mainly used for making wood pellets , the pellets used for industry, boiler factories , the machine can be produce φ6.0,φ8.0,φ10.0,φ12.0 pellets.
(2)The machine adopt imported SKF or NSK bearings, the motor brand is Siemens or china famous Wannan brand
(3)Driven by gear .more strong than by belt, and the capacity 10% higher than by belt .
(4)the machine also matched the safty equipment , once overload , the safty pin will crack, to protecting the machine lifetime .

2. 6-10mm Size Wood Pellet Machine Supplier In China Main Data:

Model Main Power(kw) Capacity(kg/h) Feeder Power(kw) Force feeder power(kw) Die Diameter(mm)
MZLH35 55 400-600 1.1 1.1 350
MZLH420 90 1000-1200 1.5 1.5 420
MZLH508 110 1500-2000 1.5 1.5 508
MZLH558 132 2000-2500 3 2.2 558
MZLH678 185 3000-3500 3 2.2 678
MZLH768 220 3500-4000 3 3 768



Working Principle of Ring Die Feed Pellet Mill(animal feed pellet mill)
The feed ingredients run through feeder into conditioner and are mixed in the conditioner with hot steam, then they go into the pelletizing chamber through blanking taper slot. By scraper the powder material enters into the pelletizing zone. And then the material will be pressed by ring die and rollers into pellets. The pellets are discharged from the die hole and cut into the requested size by the cutter.



1-10 T/H Complete Wood Sawdust Pellet Machine Wood Pellet Production Line

Features of Pellet Making Machine Price: Pellet Feed Making Machine

* ring die feed pellet making machine reaches international advanced level; it has the latest technology and low breakdown

rate;
* On the basis of Type A pellet mill, variable speed motor is added to raw material conveying to control the feeding, the

feeding is steady and reliable;
* Drive mechanism adopts high strength belt, with steady running and low noise;
* Drive mechanism adopts high quality bearing to ensure high speed and stable operation;
* Feeding part is equipped with a permanent magnet to remove metallic impurities; this prolongs the service life of main

parts and meanwhile reduce the use of auxiliary equipment.
* Convenient operation, reliable sealing, high production rate, low power consumption, low labor strength.



Sheep Chicken 1 To 10Ton/ H Poultry Feed Pellet Machine NSK Bearings 1



What Materials can be Pelletized by Ring Die Wood Pellet Machine?
Nearly all forestry and agro-waste material can be made into wood pellets by our ring die wood pellet machine, such as: Wood Chips, Shaving, Sawdust, Groundnut-shell, Sugarcane Biogases, Caster Shells/Stalk, Coffee Husk, Paddy Straw, Sunflower Stalk, Cotton Stalks, Tobacco Waste, Mustard Stalk, Jute Waste, Bamboo Dust, Tea Waste, Wheat Straw, Palm husk, Soybeans Husk, Coir Pitch Barks/Straws, Rice Husks etc. The final pellets can be used for industrial boilers and large power plants as well as home heating.



Why Choose Poultry Feed Pelletizer for your CHICKEN?
This poultry feed pelletizer for small poultry farm or home use is different from other feed pellet mills. As for chicken, they are kept for fast and health growth. The feed of chicken should emphasize the nutrition content and ingredients. We developed this homemade chicken feed pelletizer and focused to increase the integrity of nutrition and palatability which can accelerate chicken to have more than usual. What’s more, chicken in different growing stages need different size feed pellets, with this machine, you can make feed pellets from 2-10 mm, meeting different needs.



Matters need attention

1. The new machine for the first time must be run or otherwise can't be used normally.
2. When the pellet machine is working, don't reach into the input hopper by hand. If necessary, you can use a stick to help.
3. Before the machine is turned on, you need to add a little mixture before starting. When the machine is shut down, please leave a little mixture in the machine to prevent the roller and the template idling.
4. When the machine is working, and the phenomenon of stuck happens, should immediately stop and make the roller pressed to the bolt loose, and then restart the machine.
5. Each time the work is completed, the bolt of adjusting roller must be released.
6. If the machine is used for a certain period of time or squeeze out a certain amount of pellets and the pellets are made into pieces or the pellets are broken, the template should be turned to the bottom, and 2%-4% water should be added to the mixture.
7. Please often check the belt tightness to prevent the emergence of low yield, belt slippery and so on.
8. Before starting, firstly add gear oil to the gearbox reaching to 2/3 of the horizontal axis. Pellet machine in the first use should work in low load for 40 hours or so, and then replace the gearbox gear oil, 100 hours after the regular replacement. All bearings should be regularly filled with grease.
9. Particle machine works continuously and then the motor fever reaches to 70 degrees Celsius, it is a normal phenomenon.
