New Energy Flat Die Pellet Mill Home made Small Wood Pellet Machine

China New Energy Flat Die Pellet Mill Home made Small Wood Pellet Machine supplier
New Energy Flat Die Pellet Mill Home made Small Wood Pellet Machine supplier New Energy Flat Die Pellet Mill Home made Small Wood Pellet Machine supplier

Large Image :  New Energy Flat Die Pellet Mill Home made Small Wood Pellet Machine

Product Details:

Place of Origin: China
Brand Name: Rotexmaster
Certification: CE and ISO9001-2000
Model Number: YMKJ450

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: USD12000-15000 Per Set
Packaging Details: The Flat die will be paked in metal trunk , then put in Container
Delivery Time: 10-25 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200Sets Per Month
Contact Now
Detailed Product Description
Name: New Energy Flat Die Pellet Mill Homemade Small Wood Pellet Machine For Pellet Raw Materials: Waste , Tree , EFB ,etc
Capacity: 500-600 KG / H Power: 55kw
Measurement: 1700*800*1450 Mm Weight: 1300KG
Pellet Diameter: According To Requirements 3-8 Mm Color: White And Blue
Spare Parts: Mould Roller MOQ: 1 Set

New Energy Flat Die Pellet Mill Homemade Small Wood Pellet Machine For Pellet



Introduction >>>



Our wood pellet machine is our patent product, unique structure for pressing hard wood and rice husk



which with low adhesion, very difficult forming. it is the ideal compression shaping equipments for low



adhesive material.


We have the first class technology making pellet machines. And our pellet machine has very high



capacity which is suitable for big factories, power plants and others.


Our wood pellet machines can be used for wood,sawdust,straw,stalk,rice husk,corn,weeds,home



waste,factory reject and so on crude fiber granulation pelleting.The combustion rate can be raised for



several times.


Our pellet machines can be used for making pellets without any binder because of the higher pressure



they have.


Our pellet mills have CE certificate which is widely apccepted in EU and other countries all over the world.



So if you are in need of pellet machines, we are confident our pellet machines will be your best choice.



Feature >>>



1.  It adopts advanced Germanic advanced technology, with strong structure, the flat die and rollers is



Wear-resisting, heat-resistant.

2.  It have best performance die and rollers, made from high quality wear resistant alloy steel with



advanced quenching technology, increase output and extend service life.

3.  The rollers are smoothly when working, its big body and unique design increase pressing place,



increase production efficiency.

4.  Finished pellet's diameter is 6, 8mm normally, can make according to customers’ need .

5.  It have got CE,ISO9001-2000 certification, all function have achieved European level

6.  This mill with the advantage of closely structure, easily operation, stable performance

7.  The pressed pellets with high density, high fuel value, low moisture, low ash content.

8.  The gearbox is running by high precision gears. The gearbox and main shaft automatic recycling oil



adding is realized by hydraulic oil inputting system.



Materials >>>



The Flat Die Pellet Machine can be used for making livestock feed pellet , such as sheep , cattle , horse



deer ,etc. It also can be used for making soft wood pellet  , It adopts reducer transmission



Technical Parameters >>>



Model Power(kw) Diameter(mm) Capacity(T / H) Measurement(mm) Weight(T)
YMKJ350 30 / 37 3-8 300-500 1650*800*1350 0.8
YMKJ400 37 / 45 3-8 400-600 1700*800*1450 1.0
YMKJ450 55 3-8 500-700 1700*800*1450 1.3
YMKJ550 75 3-8 600-800 2350*1000*2050 2.2
YMKJ800 90 3-8 800-1000 3200*1235*2700 3.8



After-Sales Service >>>



New Energy Flat Die Pellet Mill Home made Small Wood Pellet Machine



Company >>>



Shandong Rotex Machinery CO.,LTD is a comprehensive manufacturer of bio-energy machinery, feed



machinery,organic fertilizer machinery and production lines. located in Zhangqiu, Jinan, the company



coverd 2.47 acre area, with more than usd 6.5million turnover, is the leading company in this field.Our



main products are pellet machine, hammer mill, dryer, cooler as well as the auxiliary equipment. We are



dedicated to develop and supply high quality products for domestic and overseas customers. and has



wined an outstanding reputation in international market.





FAQ >>>



I.  Q:How did you define your model as 400/450/550?


    A: The YMKJseries 400/450/550 is defined according to the main parts mould's diameter.


    For example, YMKJ400, the mold's diameter is 400 mm.


II. Q: What's the suitable moisture of material that to be granulated?


    A:The moisture should be controled under 20%


III. Q: How long is your guarantee?


     A: One Year guarantee.We shall supply free exchange for spare parts. After this period, we shall



charge at low cost to keep after service. You will be welcome to contact us with any problem might



occured.


IV. Q: Will you send engineers to install the plant?


     A: Yes, overseas engineer service is available when needed.

Please let us know the following basic information for making project


(1) What kind of material and the size of your raw material?


(2) what's the moisture content of your raw material?


(3) what's your the capacity or output you need?


(4) what's the voltage in your country?


(5) What's your requirement on the size of final pellets or usage?



If you are interested in the Flat Die Pellet Machine , please contact me .
