High Capacity Rotary Drum Dryer For Organic Fertilizer Industry , Mining

China High Capacity Rotary Drum Dryer For Organic Fertilizer Industry , Mining supplier
High Capacity Rotary Drum Dryer For Organic Fertilizer Industry , Mining supplier High Capacity Rotary Drum Dryer For Organic Fertilizer Industry , Mining supplier

Large Image :  High Capacity Rotary Drum Dryer For Organic Fertilizer Industry , Mining

Product Details:

Place of Origin: SHANDONG CHINA
Brand Name: ROTEX MASTER
Certification: CE ISO
Model Number: GHG 1.2*12

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 12,301-15000 per set
Packaging Details: Seaworthy packing
Delivery Time: 20-35 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Product Name: GHG 1.2 * 12 0.27-0.54 Ton Per Hour Capacity Rotary Drum Dryer Type: Rotary Drum Dryer
Length: 12 M Width: 1.2m
Capacity: 0.27-0.54 T/h Power: 5.5 Kw
The Thickness Of The Wall: 10-12mm Raw Materials: Wood Chips, Sawdust, Wood Shavings Etc.
Warranty: 12 Months( Except Quick-wear Part) Color: White

GHG 1.2 * 12  0.27-0.54 Ton per Hour Capacity Rotary Drum Dryer







Products introduction of rotary dryer



The rotary drum dryer is a type of industrial dryer employed to reduce or minimize the liquid moisture content of the material it is handling by bringing it into direct contact with a heated gas.



Rotary drum dryer is widely applied in biomass fuels industry, animal feed industry, organic fertilizer industry, mining, building materials, chemistry and other industries, mainly stoving wood, mineral powder, slag, clay, limestone, lignite and other materials.



Rotary drum dryers are customized drying equipment for your specific requirement. Whether you need short or long dwell time, counter-current or co-current flow structure, high or low inlet temperatures, our ROTEXMASTER’s design team are able to design rotary drying equipment which can effectively save your budget and efficiently running.



Advantages of rotary dryer

1. The rotary speed is adjustable.

2. Simple structure.

3. The dryer can dry high moisture content and large volume materials.

4. There is elastic plate sealing strip in feed inlet and outlet.

5. There is lifting blade in the inner cylinder, it can make the material mixed with the heat flow fully.

6. It is matched with stove.



Technical parameters



Model

Inner diameter(mm)

Power

(kw)

Evaporation

(t/h)

Feed water

Discharge water

Inlet temperature

Outlet temperature

Weight

(t)

YGHG0.8*12m

800

5.5

0.2-0.3















20-50%















10-20%















400-600°C















60-90°C

3

YGHG1.0*12m

1000

7.5

0.4-0.5

3.5

YGHG1.2*12m

1200

7.5

0.4-0.5

4.2

YGHG1.4*12m

1400

7.5

0.6-0.8

4.8

YGHG1.5*12m

1500

7.5

0.8

6.2

YGHG1.6*12m

1600

7.5

0.8-1

6.8

YGHG1.6*24m

1600

15

1-0.2

12.8

YGHG1.8*12m

1800

11

0.8

7.2

YGHG2.2*24m

2200

15

3.65

14.8































FAQ



    How to get the suitable model?



    Rotex: We have different model Rotary Drum Dryer.

Please tell us the moisture of the raw material, the finished-drying moisture you want and the capacity requirement, and then we will advise you the suitable model.
