Poultry feed pellet making machine with Corn , soybean and other grains Raw materials

China Poultry feed pellet making machine with Corn , soybean and other grains Raw materials supplier
Poultry feed pellet making machine with Corn , soybean and other grains Raw materials supplier Poultry feed pellet making machine with Corn , soybean and other grains Raw materials supplier

Large Image :  Poultry feed pellet making machine with Corn , soybean and other grains Raw materials

Product Details:

Place of Origin: China
Brand Name: ROTEXMASTER
Certification: CE,ISO 9001
Model Number: YSKJ120

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 800--2500 set
Packaging Details: Seaworthy packing
Delivery Time: 5-10 working days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 8000 set per year
Contact Now
Detailed Product Description
Name: 2017 High Quality Complete Animal Feed Pellet Mill Machine For Hot Sale Power: 2.2/3kw
Capacity: 80-100kg/h Raw Materials: Corn,soybean And Other Grains
Pellet Size: 2.5-8mm Color: According To Customer Request

2017 High Quality Complete Animal Feed Pellet Mill Machine for Hot Sale--

Shandong Rotex Machinery Co.,Ltd

1.Brief of Animal Feed Pellet Machine



These animal feed pellet machines are the new designed products of our company and the main parts of the fodder machinery system. Now this animal feed pellet machine is mainly used to make feed pellets for rabbit, pigeon, layer chicken, broiler, duck, goose, fish, pig and so on.The key parts are made of alloy steel that make it very strong and malleable.Now our machines have been exported to Western Europe,North America,Southern Europe,Eastern Europe Asia Africa and so on.



Pellet machine can make all kinds of solid grain into small pellet feed for animals like fish, shrimps, chicken, rabbit, horses, goats, etc.
It can also make all kinds of saw dust, paddy straw, sunflower stalk, forestry wastes, wood chips, and many other wastes into wood pellets to be used as fuels.



2.Working Principle of Animal Feed Pellet Machine



The flat die pellet machine works on vertical principle. The raw material is put into the hopper from above, and then it drops down into the pelletizing area. The die is stationery while rollers are rotating. When falling into this area, materials will naturally be compressed into pellet between rollers and die through the die holes.



3.Features of Animal Feed Pellet Machine



1) The vertical flat die pellet mills are easier to clean than big ring die pellet mill.
2) Able to change die and roller faster and easily.
3) Small and lightweight, making small-scale production.
4) Visibility. It is possible to view into the chamber when pelletizing, so you can solve any problem in time.

Poultry feed pellet making machine with Corn , soybean and other grains Raw materials

Model Power(kw) Diameter of pellets(mm) Capacity(kg/h) Size(mm) Weight(kg)
YSKJ120 2.2/3 φ2-φ6 80-100 600x450x900 50
YSKJ150 4 φ2-φ6 100-300 750x450x870 100
YSKJ200 5.5/7.5 φ2.5-φ8 300-500 1150x530x750 150
YSKJ250 11/15 φ2.5-φ8 400-700 1250x600x850 200

4.Specifications of Animal Feed Pellet Machine

1). This series machine can be powered by both diesel engine and e-motor.

2 ).We adopt the new design of direct connection of motor shaft and he main shaft that overcome the loose defect of belt connecting as long time using.

3). High accuracy gearbox and high output.

4). It is widely used in large,middle, small scale aquatic. food and feed processing factory,

livestock farm, poultry farm, individual raisers, middle and small farm.

5). International advance steam fittings and imported pressure reduction valve.

6). Flat die is made with international advanced equipment for long lifespan.

7). Drive with heavy duty gearbox, which can produce continuously in most adverse condition.

Poultry feed pellet making machine with Corn , soybean and other grains Raw materials

5.The terms of warranty and spare parts



Our pellet mills are guaranteed with 1 year quality assurance from the date of goods shipment.

When we are talking about spare parts for a pellet mill, by and large, we are talking about die, roller and bearing. Practically, that how often you will need to renew spare parts is depending on what raw material you are making pellets from. Apparently, compared with making straw pellets, pellet mill that are making wood pellets requires a higher frequency for changing spare parts. We supply clients with high quality pellet mill dies, rollers, bearings and other parts. Clients are available to order at anytime. If you need spare parts, please contact me or test message.
