Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560

Good quality Small Pellet Mill for sales
Good quality Small Pellet Mill for sales
Rotexmaster, is recommended!!!

—— Mojo

Good equipment and also good service, I believe them!

—— Erhan

ROTEX machine is really good quality,I bought one for wood pellet high efficiency.

—— Mike

I bought ROTEX machines,how it’s really good efficiency,and their after sales service is pretty nice,engineers gave me strong support.Thanks very much

—— Wade

Quality is first ! Good service ! This is ROTEX MASTER.

—— Yasin

I am a trader, and I like to cooperated with ROTEX MASTER, they gave me good machines, and I got much profits, I am glad work with them.

—— Ladi

I'm Online Chat Now

Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560

China Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560 supplier
Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560 supplier Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560 supplier

Large Image :  Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560

Product Details:

Place of Origin: China
Brand Name: Rotexmaster
Certification: CE ISO
Model Number: YGKJ560
Contact Now
Detailed Product Description
Full Name: Compress Wood Pellet Mill Usage: To Make Wood Pellets
Power: 90+1.5+1.5+0.37+0.55kw Motor Brand: Siemens Beide
Raw Material: Sawdust And Other Wood Related Material , Agricultural Waste Output: 1-1.5t/h
Pellet Standard: 6mm Or 8mm Is Popular

Warranty 1-1.5t/h compress wood pellet mill

introduction of compress wood pellet mill

1. Rotexmaster YGKJ series efficient vertical ring die pellet machine is an ideal dense compression molding equipment.

2. Rotexmaster vertical ring die pellet machine is mainly applicable for difficult molding materials with low adhesion rate, such as rice husk, shell of sunflower seed, peanut shells and other various shells material; tree branches, wood sawdust, all kinds of wood scraps; corn stalk, cotton stalk, all kinds of crops straw;

3. Rotexmaster vertical ring die pellet machine widely used in making fuel materials for home use fireplace, power plant, wood processing plant, biomass fuels plant and large-scale complete pellet production lines.



Features of wood pellet mill compress machine

1. Forming rate: over 98% formation
2. Vertical feeding hopper: vertical feeding, distribute evenly in pelleting room
3. Double-layer die: double use, less cost and high efficiency.
4. Motor: Siemens famous brand
5. Bearing: Harbin bearing
6. Reducer: China famous GUOMAO reducer
7. Die is static, rollers rotate. centrifugal force make the pressing force big in pellitizing.
8. Cooling system. cooling system avoid the heat rise, prolong the service life of die and bearing.

9. Automatic lubricate system. automatic lubricate to make machine can work 24 hours per day continously.

Model Power  kw  Output t/h  Dimension mm Weight t
YGKJ560 90+1.5+1.5+0.37+0.55 1-1.5 2600*1300*2300 5.8
YGKJ680 160+1.5+1.5+0.37+0.55 1.5-2.5 3300*1500*2300 8.5
YGKJ850 220+3+2.2+0.37+0.55 2.5-3.5 3800*1830*3080 15

FAQ

Our questions to ask customer for design suitable production line for them?

1. What is ur material?

For different material, we will design different width die according to its different compression ratio.

2. What is the shape, size and moisture content of ur material?

if it is wood timber, wood logs, the wood chipper, hammer mill will need.

if it is wood branch, twigs, or plates, the hammer mill will need.

if the moisture content is over 15%, the drier will need. the suitable content is 10% -15% (moisture) for enter into the pellet mill machine.

3. How many output capacity per hour/month/year?

we will decide which model of pellet mill and its production line acording ur output capacity.

4. Ur country industrial voltage and Hertz?

pls tell me ur local voltage and hertz, we will modify the motor in advance.



Customers' questions for asking us?

1. Are you a factory or a trading company?

we are a China leading manufacturer in pellet mill machine field.

2. Do you have certificates of ur wood pellet mill?

yes, we have passed CE, ISO, SGS, BV certificates.

3. Will you supply oversea installation?

Yes, dear. we will send technicians to ur country as per ur request.

4. What is ur warranty time?

12 months since ur receiving our machine.

5. Lifespan of wearing spare parts?

Die: two materials: alloy steel: 800-1000hour Stainless steel: 1000-1200hour

Roller: one material: alloy steel: 500-800 hour

6. How can i get to ur factory?

You can get a flight to Jian Airport. it takes about 40-50mins away from here to our factory.



Commercial terms:

Delivery time: 20 work days after receiving ur 30% prepayment

Payment term: 30% T/T prepayment, 70% T/T balance payment before delivery date.

Container: 20"GP, 40"GP or 40" HQ according ur order.

Price validity: 1 month

Trade terms: FOB, CFR or CIF prices.

Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560

Warranty 1-1.5 t/h compress wood pelelt mill production line YGKJ560
