5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy

China 5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy supplier
5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy supplier 5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy supplier 5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy supplier 5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy supplier

Large Image :  5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy

Product Details:

Place of Origin: China
Brand Name: ROTEXMASTER
Certification: CE & ISO & SGS & BV
Model Number: YSKLN4

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: 12500- 13000 USD/SET
Packaging Details: Seaworthy Packing
Delivery Time: Within 15-20 days
Payment Terms: D/A, L/C, T/T, D/P, Western Union, MoneyGram
Supply Ability: 500 Sets Per Year
Contact Now
Detailed Product Description
Products Name: Rotex 5-8 Ton/h Counter Flow Cooler Power: 3+0.37kw
Capacity: 5-8t/h Usage: Used For Cooling Wood Pellets,feed Pellets Etc.
Cooling Volume: 4m³ Cooler Size: 2300*2150*3190mm
Whole Set Cooler: Air Lock,Cyclone,Fan Blower And Simple Screener After-sales Service: Professional,Prompt,On Time
Products Temperature After Cooling: 3-5℃

Rotex 5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy




≥ Features of Counter Flow Cooler

1. The temperature of pellets after cooling is not +5 °Chigher than room temperature.
    The reducing moisture rate is not lower than 3.8%. All these are good for producing high capacity feed
    pellets, lengthening pellets storage period and improving economic efficiency.
2. Shut down automatic nesting with the unique effect, to avoid cross contamination between
    feed.
3. Unique nesting box nesting force.
4. SKLN series with the secondary spiral separator used in combination.
5. Suitable for cooling a variety of pellets material.




≥ Work Principle of Counter Flow Cooler

ROTEX counter flow cooler has the special cooling theory ,the cool air and pellet move inversely.
The pellets are cooled from bottom to the top gradually ,which avoid the split of pellet surface, the heart moisture and  heat  emanate  uneasily  during  the  cooling  process  and  so  on characteristic  by using old type vertical cooler.


≥ Technical parameters of Counter Flow Cooler




        5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy

Model

SKLN1.2

SKLN1.5

SKLN2.5

SKLN4

SKLN6

Output(t/h)

0.5-0.8/0.8-1

1-2

3-5

5-8

8-12

Cooling cubage(m3)

1.2

1.5

2.5

4

6

Cooling time

Not Less than 6-10 min

Cooling temperature

Not higher than room temperature 3-5 celsius

Power(kw)

1.1+1.5/1.5+0.25

1.5+0.25/1.5+1.5

2.2+0.55/2.2+2.2

3+0.37/2.2+3





4+0.37/3+5.5





 ≥ More Picture Show for Counter Flow Cooler

              Full Set Counter Flow Cooler - Air Lock , Cyclone , Fan Blower , Screener
5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy

5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy

5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy
 5-8 Ton/h Counter Flow Cooler for Cooling Animal Feed Pellets in Low Energy
