4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm

I'm Online Chat Now

4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm

4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm
4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm
4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm 4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm 4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm 4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm 4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm

Large Image :  4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm

Product Details:
Place of Origin: China
Brand Name: MIKIM
Certification: CE
Model Number: 36,40,42
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $500.00 - 910.00/ Set
Packaging Details: packed by wooden export package or loading by container
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

4600r/ Min Corn Stalk Hammer Mill Machine Wheat Crusher 0.5m To 5mm

Description
Name: Grain Crushers Hammer Mill Machine Feed Fodder Crusher Machine Main Shaft Speed(r/min): 4600
Warranty: 1 Year Condition: New
Type: Hammer Mill Capacity(t/h): 150-2000kg/h
Screen Size(mm): 0.5-30 Hammer Quantity: 12
High Light:

4600r/ min Hammer Mill Machine

,

corn stalk hammer mill 5mm

,

wheat crusher machine 0.5m

Grain Crushers Hammer Mill Machine Feed Fodder Crusher Machine



The feed crusher is used for grinding biomass, like straw/stalk/tree branches and forest waste, grains like corns, soybeans and maize etc into small granular material of less than 3-5mm, which is perfect size for pelletizing and briquetting.

Grain Crushers Hammer Mill Machine Feed Fodder Crusher Machine

Work Principle:

When this series hammer mill/animal feed crusher work, the raw materials will be fed to crushing room through the feeder, under the impact/crash of high speed rotating hammers, the raw materials will be crushed rapidly, then go through the screen and be sucked to the outlet. The size of screen can be customized as requirements.



Technical Parameters:

Model 9FQ-36 9FQ-40 9FQ-42 9FQ-50
Rotor Diameter(mm) 360 400 420 500
Power Motor(KW) 5.5-7.5 7.5-11 11 22-30
  Diesel Engine(HP) 10 15 16 35-40
Main Shaft Speed(r/min) 4600 4000 3200 3400
Crushing Room Width(mm) 202 202 280 400
Hammer Quantity 12 12 16 24
Screen Size(mm) 0.5-5 1.2-8 1.2-20 1.2-30



Main Features

This Feed mill is mainly composed of frame, shell, coupling, hammer, screen, pulley, electric frame, motor, feed foil, etc.The structure is simple and reasonable, hammer is made of manganese steel with high wear resistance,and the material size of the finished product can be adjusted according to the size of sieve mesh, power consumption is small, service life is long, and the production can be moved, which is very convenient.



Our Services

Pre-sale service:

1. Provide our client with investment guide for free.

2. Provide our client with evaluation investment scheme for free

3. Free visit to our factory.

4. Design of production line scheme is provided for free.



In-sale service:

1. Experienced workers are sent to provide track service when equipment is transported.
2. Experienced technicians or engineers will be sent for on-site installation, adjustment and technical devices according to clients' engineering requirement.
3. "Operating instruction manual", equipment assembly drawings and wearing parts list in duplicate will be provided for free.



Post-sale service:

1. On the premise that equipment is operated correctly and in warranty period, we accept repair, exchange, and return items.
2. We provide permanent favorable spare parts for our clients.

3. We provide permanent technology support and related help.
