Product Details:
|
| Name: | Thickness Adjustable Automatic Wood Shaving Machine For Sale Wood Chipping Machine | Power(w): | 11-55kw |
|---|---|---|---|
| Weight: | 500kg | Voltage: | 380v ,Customized |
| Dimension(l*w*h): | 2000*870*1500mm | Capacity: | 300-2000kg/h |
| After-sales Service Provided:: | Online Support | Spindle Speed(r/min): | 1500 |
| High Light: | pto wood shredder machine,wood shredder machine 1500MM,wood chipping machine 1500*640*820mm |
||
Production Characteristics
1. This product is reasonable in design, reliable in quality, simple in structure, convenient in operation, small in volume, less
in occupation of space, and energy-saving in labor and electricity.
2, the equipment is divided into electric version and diesel version of two models, according to their own needs to choose the model.
3. The main parts of the product are made of thickened steel plates, which are strong and durable. The cutting tools are specially treated and can be operated continuously.
4. Suitable for all kinds of raw materials (corn straw, cotton stalk, corn cob, branches, leaves, green garbage, etc., or wood
factory scraps, etc.)
Product Overview
Wood Shavings Machine
The wood shaving machine produced by our company is a new product that adopts new technology and then improves it according to the needs of wood shavings and the current status of wood. This wood shaving machine can process all kinds of wood (such as sticks, branches, logs, furniture scraps from furniture factories, waste wood branches, etc.) into batches of thin wood shavings with uniform thickness. The wood enters the machine through the feed port and is sliced by the blade inside the machine to punch the shavings. The size and thickness of the shavings are even, which is not much different from the wood shavings produced by the wood factory, it also saves time and labor. The use of wood shavings: it can be used as particleboard (plywood), as a raw material for wood pulp paper in paper mills, as a transport filler for fragile products transportation companies, as stuffing in the nests of pigs, cattle, sheep, and various animals, and can also be used as bioenergy.
Featrues
| Type | Knives qty | Input size(mm) | Cutter dia(mm) | Blade size(mm) | Output(t/h) | Spindle speed(r/min) | Power(kw) | Size(mm) |
| MFJ-420 | 4 | 160*155 | 424 | 90*60*8 | 0.8-1.5 | 2600 | 7.5-11 | 1200*550*750 |
| MFJ-500 | 4 | 210*180 | 510 | 120*70*8 | 1.2-2.0 | 2400 | 18.5-22 | 1500*640*820 |
| MFJ-600 | 4 | 235*200 | 600 | 150*70*8 | 1.8-2.5 | 2200 | 22-30 | 1600*700*1050 |
| MFJ-700 | 4-6 | 230*200 | 600 | 180*70*8 | 2.5-3.5 | 2000 | 30-37 | 1850*830*1050 |
| MFJ-900 | 8 | 280*290 | 750 | 150*100*10 | 5.5-6.5 | 1500 | 55-75 | 2000*870*1500 |
| MFJ-1000 | 8 | 280*290 | 750 | 150*140*10 | 6-7 | 1500 | 75-6 | 1180*1100*940 |
| MFJ-1200 | 8 | 390*385 | 1000 | 190*140*12 | 7-8.5 | 1200 | 90-6 | 1430*1500*1200 |
| MFJ-1500 | 8 | 425*500 | 1160 | 230*140*14 | 9-11 | 1000 | 110-6 | 1650*1750*1400 |
| MFJ-1800 | 12 | 530*560 | 1300 | 150*140*14 | 11.5-14 | 950 | 132-6 | 2050*1850*1620 |
