Product Details:
|
| Name: | Automatic PLC Control 500-1500 KG/H Forage Grass Feed Pellet Machine For Pellet Making | Voltage: | As Clients Requested |
|---|---|---|---|
| Power(w): | As Clients Requested | Condition: | New |
| Weight: | 2000 Kg | Dimension(l*w*h): | According To The Actual |
| Capacity: | As Clients Requested | Advantage: | High Efficiency |
| High Light: | PLC Control forage pellet mill,automatic pellet making machine PLC,500KG/ H automatic pellet making machine |
||
Automatic PLC Control 500-1500 KG/H Forage Grass Feed Pellet Making Machine For Pellet Making
Grass Feed Pellet Machine with the international advanced level, the latest technology, low failure models. On the basis of the A type ring mould granulator, the feeding of the raw material is controlled by the variable speed motor, the feeding is uniform and convenient. Transmission parts using high-strength belt drive, smooth operation, low noise. Rotary parts of the selection of high-quality bearings, to ensure high-speed rotation stability.The addition of a permanent magnet to the cutting part of the device, increasing the service life of the main components while reducing the same type of auxiliary equipment. Easy operation, reliable sealing, high production efficiency, low energy consumption, low labor intensity.
Stainless Steel Ring Die and Bearing
1. Structure: Compact structure, easy operation, installation and maintenance;
2. Ring Mode: Equipped with different aperture ring modes;
3. Conditioner: Standard and large stainless steel conditioner can be chosen;
4. Special Design: Stainless steel discharge chute and door closure, Anti-corrosion and durable;
5. Feeder: Strong full stainless steel feeder, feed smoothly, to prevent the plugging material;
Technical Parameters of Feed Pellet Making Machine:
| Type |
Power of Main Moter(kw)
|
Capacity (t/h) | Power of Feeding Motor(kw) | Power of Conditioner(kw) | Diameter of Ring(mm) | Size of Finished Pellets(mm) |
| SZLH250 |
11×2
|
0.4-1 | 0.75+1.5 | 2.2 | 250 | φ6-10 |
| SZLH350 |
30×2
|
3-5 | 0.75+1.5 | 2.2 | 350 | φ6-10 |
| SZLH420 | 45×2 | 3-12 | 0.75+2.2 | 5.5 | 420 |
φ6-10 |
| SZLH520 | 55×2 | 5-18 | 0.75+2.2 | 7.5 | 520 |
φ6-10 |
Application of Grass Feed Pellet Machine
1. With grain,corn,wheat ,sawdust, crop straw (corn stalks, sorghum stalk, soybean stalk, cotton stalk, rape straw, peanut seedlings, and sunflower stalk), rice husk, grass, shrubs, branches, wood cut-off head, bamboo debris, bagasse and the like as raw materials; through high-temperature extrusion, the finished pellets are of cylindrical shape, spherical shape, and honeycomb shape,used for animal feed and fuel.
2.Main drive equipped with dual motor drive belt, ring die with fast-equipped hold hoop.
Whole transmission parts (including motor) chooses high-quality bearings made in Swiss, Japanese to ensure the transmission efficient, stable.
3.Adopting international advanced technology: German gun drill and vacuum furnace heat manufacturing process, with high-quality and long service life alloy steel ring die to ensure the pellets smooth and of high quality.
Features of Grass Feed Pellet Machine
1.This mill widely applied product with mature technology .
2.The main driving adopts high-precision gear drive, so that the output is improved by about 20% when compared with that of belt drive.
3.Imported high-quality bearing and oil seal are adopted to ensure efficient, stable and low-noise whole machine operation . the granulating room is equipped with air suction temperature reducing system .
4.The feeder adopts variable-frequency and variable-speed motor to ensure the quality of discharged particles .
5.Ring dies with multiple kinds of bore diameters are optional . and high-quality craft ring dies are adopted, so that the service life is long. The discharged particles are smooth and the quality is high .
6.International advanced compensation type snakelike spring coupling has the propertied of novel and compact structure, high safety, low noise and low fault rate.
7.Plus-size conditioner and jacket type conditioner are selectable to strength the particle conditioning effect.
